Pro Comp PRO-X Twin Tube Steering Stabilizer – 219500B

Pro Comp Suspension

Shop Toyota Pickup Steering Stabilizers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Fits 1986–1995 Toyota 4Runner and Toyota Pickup per Pro Comp’s list
  • Extended 19.91 in, collapsed 12.17 in, travel 7.74 in
  • Twin tube design with 5/8-inch chrome hardened shaft
  • Loop mounts both ends; brackets not included
  • Part number EXP219500B, sold individually

Description

Overview

The Pro Comp PRO-X Twin Tube steering stabilizer, part number EXP219500B (model 219500B), is a single hydraulic steering stabilizer with loop mounts at both ends. It fits the 1986–1995 Toyota 4Runner and the 1986–1995 Toyota Pickup.

A steering stabilizer, also called a steering damper, slows side-to-side movement of the steering. This one reduces bump steer caused by oversized tires or rough roads, and reduces wheel vibration that can fatigue suspension parts. The twin tube design has a 5/8-inch chrome hardened piston rod and a Teflon rebound stop. It suits highway comfort and demanding off-road driving. It is sold individually, and the shock boot is sold separately. It improves handling across a range of road conditions and comes in extended lengths.

Key features

  • Twin tube hydraulic design
  • Intended to reduce bump steer and wheel vibration
  • 5/8-inch chrome hardened shaft
  • 1-3/8-inch nylon banded piston
  • Teflon rebound stop
  • Loop mounts at both ends, black powder coat finish

Choosing mounts and brackets

Loop-style ends depend on the brackets that hold them. Brackets are not included with this stabilizer, so plan the mounting points on both ends before ordering, and confirm that the brackets you choose match the loop at each end. A stabilizer that cannot seat fully at both mounts will bind or load the wrong parts.

The stabilizer works best when the steering linkage is in good shape. Worn tie rods, ball joints or a loose pitman arm let the stabilizer do more work than it was built for. Check the tie rod ends and steering box mounting before fitting the new unit, and replace any worn parts at the same time.

  • Measure the mount spacing before ordering
  • Use brackets sized to the loop ends
  • Check the body for leaks after the first drive

Specifications

Brand Pro Comp Suspension
Part number EXP219500B
Series PRO-X hydraulic steering stabilizer
Single or dual Single
Type Stabilizer only
Extended length 19.91 in
Collapsed length 12.17 in
Travel length 7.74 in
Body diameter 2.36 in
Upper mount Loop
Lower mount Loop
Piston 1-3/8 in nylon banded
Shaft 5/8 in chrome hardened
Finish Black powder coat
Shock boot Not included, sold separately
Brackets Not included

Vehicle fitment

It fits the 1986–1995 Toyota 4Runner (DLX and SR5 trims) and the 1986–1995 Toyota Pickup (Base, Base Turbo, DLX, SR5 and SR5 Turbo trims).

Other Toyota generations and models are not on the list. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Brackets are not included, so plan the mounting points for both loop ends before ordering.

What’s included

One steering stabilizer, sold individually.

Not included: Mounting brackets for the loop ends, and the shock boot, which is sold separately.

Fitment

VehicleYearsTrims
Toyota 4Runner1986–1995DLX, SR5
Toyota Pickup1986–1995Base, Base Turbo, DLX, SR5, SR5 Turbo

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will this stabilizer fit a 1990 Toyota 4Runner?

Yes. It fits the 1986–1995 Toyota 4Runner in the DLX and SR5 trims, so a 1990 4Runner falls within the covered years. Confirm your trim before ordering.

Does it come with brackets?

No. Brackets are not included, so you need separate brackets to mount the loop ends on each side of the stabilizer.

Is a shock boot included?

No. Pro Comp sells the stabilizer individually, and the shock boot is an optional extra bought separately from it. Check the boot's availability for your application before ordering it.

What are the extended and collapsed lengths?

It extends to 19.91 inches and collapses to 12.17 inches, giving 7.74 inches of travel. The body diameter is 2.36 inches, so check the space between your mounts against those lengths before installing.

Can a steering stabilizer help with a shaky steering wheel?

It can reduce vibration when the cause is wheel or tire movement, but it does not fix worn steering parts. If the shake remains, check the tire balance, tie rods and wheel bearings before relying on the stabilizer.
