Overview
The Rough Country V2 front monotube shock R/C760740_B is a nitrogen-charged front shock for the 1971–1980 International Scout II with a lift of 3 to 4.5 inches. It has a monotube body of T6061 brushed aluminum and a black anodized finish.
A floating piston inside the body keeps the oil and high-pressure nitrogen apart, which helps prevent cavitation. The internal piston is a 46mm high-flow unit, and the shock is designed to be mounted body-up. In a monotube design the oil and gas share one tube with a floating piston between them, rather than the two-tube layout of a twin-tube shock. Check the mounts against your existing shock before ordering.
Key features
- Monotube shock with nitrogen charge
- Internal floating piston keeps oil and nitrogen apart
- T6061 brushed aluminum body with black anodized accents
- 46mm high-flow internal piston
- Body designed to shed heat faster
- Designed for body-up mounting
Using shocks on a Scout II
A Scout II with a larger lift puts more travel and more load on the front shocks, especially on rough trails and steep side slopes. Monotube shocks are common in these setups because the single tube handles heat well over long climbs, and the floating piston keeps gas and oil from mixing as the shock works.
Before you buy, confirm that the truck’s lift falls within the range this shock is built for, and check the front bracket geometry, since older Scouts often have worn mounts. Steering components, tie rod ends and front control arm bushings are often replaced at the same time, so inspect them while the front is apart.
- Measure front ride height before ordering
- Check old brackets for wear or cracks
- Inspect tie rod ends during the swap
Specifications
| Brand | Rough Country |
|---|---|
| Part number | R/C760740_B |
| Product line | V2 Series |
| Shock type | Monotube |
| Position | Front |
| Lift height | 3-4.5 in. |
| Body material | T6061 brushed aluminum with black anodized accents |
| Piston | 46mm high-flow, internal floating design |
| Charge | Nitrogen |
| Mounting | Body-up |
| Fitment | Direct fit |
Vehicle fitment
It fits the 1971–1980 International Scout II in Base, SS2, Terra, Traveler and XLC models. It is sized for a 3 to 4.5 inch lift. Confirm your vehicle’s year, model and trim before ordering.
The list covers the Scout II only, so other Scout years and other International trucks are not included. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Mount the shock body-up as the design calls for, and confirm your front suspension sits within the 3 to 4.5 inch lift range before ordering.
What’s included
One front V2 monotube shock, part number R/C760740_B.
