Overview
The G251PBLT is a dual rate long travel suspension lift system for the 2020–2026 Jeep Gladiator, with lift heights from 0 to 3.5 inches. It uses 1.5 in. rear coil springs and Black MAX shocks at the front and rear, and it is a direct fit for the Gladiator Overland, Sport and Sport S.
A dual rate spring uses two spring rates. The first rate gives a comfortable highway ride and expands during articulation so the tires stay in contact with the ground longer. The second, lower rate engages only after the spring compresses past the first rate, keeping the vehicle controlled during body roll and heavy off-road travel.
Key features
- Dual rate spring design with a first rate for highway ride and a second rate for off-road travel
- Unique left and right coil springs, as with original equipment
- Long travel front and rear shocks, length-fitted to allow full extension for articulation
- Black MAX front and rear shocks
- Rear coil springs with a variable second stage for loads when overlanding or towing
Dual rate spring behavior
A dual rate spring behaves differently as it compresses. The softer first rate keeps daily driving comfortable, while the second rate stiffens once the spring travels farther, which helps limit body roll and bottoming on rough trails. This matters most on trucks that carry loads or tow, because the stiffer stage handles added weight.
Because the spring rate changes mid-stroke, shock length and damping need to match the travel the system allows. Long travel shocks are fitted to allow full extension, and worn shock mounts or bushings can reduce that range. Check the rear coil springs and their seats during regular service, and watch for cracking or sagging.
- Check rear coil seats for cracking
- Inspect shock mounts and bushings
- Look for leaking shock bodies
- Confirm full extension after installation
Specifications
| Brand | Skyjacker |
|---|---|
| Part number | SKYG251PBLT |
| Kit type | Suspension lift kit, 2.5 in. |
| Lift height range | 0 to 3.5 inch |
| Rear coil spring | 1.5 in. |
| Rear lift component | Coil spring |
| Front shocks | Black MAX |
| Rear shocks | Black MAX |
| Fitment type | Direct fit |
Vehicle fitment
The system fits the 2020–2026 Jeep Gladiator (JT) in the Overland, Sport and Sport S versions.
The list does not cover the Gladiator Rubicon or the Wrangler JL. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
A suspension lift changes ride height and driveline angles, so the alignment and driveline angles should be checked once the system is installed. Measure the existing lift before choosing a system, since this one covers 0 to 3.5 inches.
What’s included
The system includes Black MAX front and rear shocks and rear coil springs. Confirm the front components before installation.
Not included: Any front spring not covered by the components above.
