Titan 50 Gallon Mid-Ship Fuel Tank – 7040216

Titan Tanks

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Fits 2016–2019 Nissan Titan XD in PRO-4X, Platinum Reserve, S, SL and SV trim
  • 50 gallon mid-ship tank made of cross-linked polymer, no drilling or cutting required
  • Includes 2 rear straps, center point and front mounting bracket, rollover vent valves
  • Part number 7040216, UPC 848135001482
  • Lifetime Warranty

Description

Overview

The Titan Tanks 7040216 is a 50 gallon mid-ship fuel tank for the 2016–2019 Nissan Titan XD. It is a direct replacement for the stock tank and fits Crew Cab models with 6 ft 7 in beds. Installation does not require drilling, cutting or fabrication.

The tank is made from military grade, cross-linked polymer (XLHDPE), which is tougher than steel and holds up better than aluminum. Its tapered design uses a low fuel trap so every gallon can be used, and it hangs only 2 inches below the bottom of the stock tank. In drop testing, the tank was filled completely and dropped 30 feet onto a steel plate without losing a drop of liquid.

The tank carries a Lifetime Warranty and is built for long service life.

Key features

  • Extended capacity and extra heavy duty construction
  • Tapered design with a low fuel trap so every gallon can be used
  • Hangs only 2″ below the bottom of the stock tank
  • Cross-linked polymer, described by Titan as tougher than steel
  • Four mounting support points: two rear straps, one center point mounting system and one front mounting bracket
  • Gen V sending unit mounting system
  • Rollover safety vent valves included
  • No drilling, cutting or fabrication required
  • Titan says installation takes one person and 2.5 hours
  • Lifetime Warranty

Mid-ship tank ownership tips

A mid-ship tank changes where the truck carries its fuel, so the balance and clearance around the frame and driveline matter more than they would with a stock tank. Hanging the tank a short distance below the stock position leaves less space for ground clearance on rocky trails, so check the lowest point of the tank and its shield after every rough outing. The straps and front mounting bracket carry most of the load, and they should be inspected for flattened bushings, loose fasteners and rubbing marks on the frame.

Good habits keep the tank performing for years. Keep fuel fresh by using it steadily, since fuel that sits can pick up water and degrade. Recheck the sending unit wiring and vent routing whenever the fuel system is opened, and replace any cracked or hardened vent hoses before they restrict airflow. If the truck is used for towing or hauling, consider how the extra fuel weight affects payload and tongue load, and adjust loads so the rear axle stays within its rated limits.

Specifications

Brand Titan Tanks
Part number 7040216
UPC 848135001482
Capacity 50 gallon, extended
Material Military grade cross-linked polymer (XLHDPE)
Mounting support points 4
Position below stock tank Hangs 2″ below the bottom of the stock tank
Warranty Lifetime Warranty
Fitment type Direct fit

Vehicle fitment

The 7040216 fits the 2016–2019 Nissan Titan XD in PRO-4X, Platinum Reserve, S, SL and SV trim. It is a direct fit, and it is designed for Crew Cab models with 6 ft 7 in beds.

Nissan Titan model years outside 2016–2019 and other Nissan models are not covered. Confirm the year, model and trim before you order.

Installation notes

Titan says one person can install the tank in 2.5 hours without drilling, cutting or fabrication. Work with the battery disconnected and the fuel system depressurized, away from ignition sources.

What’s included

The kit includes 2 rear straps, 1 center point mounting system, 1 front mounting bracket, rollover safety vent valves and the accessories needed for installation. Check the package contents against your installation before starting, including whether a sending unit or fuel pump is needed.

SKU: TTN7040216 Category:

Specification

Shipping weight 75.00 lbs
Package dimensions 94.00 × 21.00 × 20.00 in
brands

Fitment

VehicleYearsTrims
Nissan Titan XD2016–2019PRO-4X, Platinum Reserve, S, SL, SV

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will the Titan 7040216 fit a 2016 to 2019 Nissan Titan XD?

Yes. It fits the 2016–2019 Nissan Titan XD in PRO-4X, Platinum Reserve, S, SL and SV trim, including Crew Cab models with 6 ft 7 in beds. Check your model year and trim before ordering.

Does the 7040216 require drilling?

No. The tank is a direct replacement for the stock tank, and installation does not require drilling, cutting or fabrication. Four mounting support points hold it in place.

What comes with the 7040216?

The kit includes 2 rear straps, one center point mounting system, one front mounting bracket and rollover safety vent valves, along with the accessories needed for installation. Check the package contents against your installation before starting, including whether a sending unit or fuel pump is needed.

How big is the 7040216 tank?

It is a 50 gallon tank. It hangs 2 inches below the bottom of the stock tank and uses a tapered design with a low fuel trap, so every gallon can be used.

Can the tank be drained for storage or service?

Yes, drain it before removing or servicing the tank, since fuel system work carries fire risk. Work with the battery disconnected, in a ventilated area away from open flames, and take old fuel to a proper collection site. Ask a qualified technician for help if the tank will sit empty for a long period.

Does a lower-hanging tank need extra protection?

Often, yes. A tank that sits lower than the stock position can meet rocks, stumps and ruts first. Check whether a skid plate or shield suits your driving, and confirm it clears the tank, straps and vent hoses before installing.
