Overview
The Pro Comp K4038B is an 8-inch stage 1 coil spring lift for Ford F-250 and F-350 Super Duty trucks from 2005 to 2007. The front uses coil springs with radius arm drop brackets, and the rear uses springs and U-bolts with leaf springs.
An ES9000 front shock is included, along with front sway bar links, bump stop extensions and brake line extension brackets. A pitman arm is included for steering correction, and the lift height range is 7 inches and up.
Key features
- 8-inch lift, stage 1
- Front coil springs with radius arm drop brackets
- Front sway bar links and bump stop extensions
- Pitman arm steering correction
- Brake line extension brackets
- Rear springs and U-bolts
Front geometry after installation
Coil springs with radius arm drop brackets change the front geometry at the arm mounts, so caster, camber and steering angle should be checked after installation. The raised front end also changes how the sway bar and the steering linkage sit. Inspect the drop brackets and their bolts for cracks or movement after the first few drives.
Rear springs and U-bolts carry the back of the truck, and driveline angles should be checked once they are fitted. Brake line extensions help the lines reach the raised front end without stress. Pitman arm correction is often needed on lifts of this size, and steering centering should be confirmed once the alignment is finished.
- Inspect drop bracket mounts for movement
- Check rear driveline angles
- Confirm steering centering after alignment
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | K4038B |
| UPC | 614901124767 |
| Lift | 8 inches, stage 1 |
| Lift height range | 7 inches and up |
| Suspension type | Radius arm |
| Front lift | Coil springs with radius arm drop brackets |
| Rear lift | Springs and U-bolts |
| Steering correction | Pitman arm |
| Front shocks | ES9000 |
Vehicle fitment
It fits 2005-2007 Ford F-250 Super Duty and F-350 Super Duty trucks. Make sure your year, model and trim match the kit before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
An 8-inch lift with radius arm drop brackets changes the front geometry substantially, so the alignment and caster need to be set afterwards. Check the rear driveline angles once the springs and U-bolts are installed.
What’s included
The kit includes front coil springs, radius arm drop brackets, front sway bar links, bump stop extensions, a pitman arm, brake line extension brackets, rear springs and U-bolts, and an ES9000 front shock.
