Overview
The kit installs without cutting the factory cross members and provides clearance for 35 inch tires on 2WD and 4WD 2007–2018 Toyota Tundra trucks. The front uses extended steering knuckles.
Extended steering knuckles keep the rack and pinion in its factory location, which preserves the factory steering geometry. The kit uses a rock proof, CNC laser cut, one-piece lower cross member and is compatible with the factory VSC electronic stability control system.
The knuckle design keeps proper CV axle angles and lets the suspension travel through its full range of compression and extension without binding the ball joints. The rear uses lift blocks with U-bolts and add-a-leafs.
Key features
- 4 inch stage 1 lift, with a lift height range of 3 to 4.99 inches
- Extended steering knuckles that keep the rack and pinion in its factory location
- One-piece, CNC laser cut lower cross members
- Clearance for 35 inch tires
- Compatible with the factory VSC electronic stability control system
- Strut extensions, cross members, bump stops and sway bar drop brackets included
- Shocks included, with the front shocks reusing the original units
Steering and driveline checks
A four inch lift that keeps the rack and pinion in place changes the front suspension angles, so the steering feel and tire wear can shift. Extended knuckles let the factory steering unit stay where it was, which keeps the steering geometry closer to the original. Alignment is the final step after any lift.
CV axle angles are a common concern on trucks lifted this height. Watch for vibration at speed, clicking on turns and torn boots, since these show the axle is working at a steep angle. Rear lift blocks add driveshaft angle, so the driveline should be checked too.
Trucks used for towing or frequent off-road trips see more load on joints and mounts. Check the bump stops, strut extensions and sway bar drop brackets at regular intervals to keep the setup predictable.
- Check CV boots for tears
- Inspect sway bar drop bracket fasteners
- Re-torque hardware after the first drive
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | K5079B |
| UPC | 70000575841 |
| Lift height | 4 inches, stage 1 |
| Lift height range | 3 to 4.99 inches |
| Suspension type | Knuckle |
| Front lift method | Crossmember, steering knuckles and strut spacers |
| Rear lift method | Lift blocks with U-bolts and add-a-leaf |
| Tire clearance | 35 inch tires |
| Shocks | Included; front shocks reuse the original units |
| Electronic stability control | Compatible with factory VSC |
Vehicle fitment
It fits the 2007–2018 Toyota Tundra in the 1794 Edition, Base, Limited, Platinum, SR, SR5 and TRD Pro trims.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Because the kit installs without cutting the factory cross members, the original cross members stay in place. The kit changes steering and driveline geometry, so plan on a full alignment after installation and a check of the CV axle angles.
What’s included
Strut extensions, cross members, bump stops and sway bar drop brackets, with shocks included. Check the package contents against your installation before starting.
