Front Axle U-Joints
Showing 13–19 of 19 resultsSorted by popularity
-
Dana 44 U-Joints
Alloy USA Dana 44 Extreme Duty Axle U-Joints – 11500
- Alloy USA extreme duty U-joints, part 11500, for Dana 44 axles
- O.E.M style needle bearings rather than bushings
- Snap ring to snap ring size 2.188 inches, cup size 1.188 inches
- Highway rated and lubeable
- UPC 80431418134
SKU: ALY11500 -
-
Front Axle U-Joints
Dana Spicer AAM 9.25ion. Heavy Duty Axle U-Joint – 5006813
- Heavy duty forged cross U-joint for the AAM 9.25 front axle
- Inside and outside snap rings, not lubeable
- Part number 5006813, UPC 23913121204
- Universal fit with 1.375in cup size and 3.000in snap ring spacing
SKU: D/S5006813 -
-
Dana 44 U-Joints
Dana Spicer JK Wrangler Rubicon Axle U-Joint – 5-7166X
- Dana Spicer Dana 44 axle U-joint, part number 5-7166X
- Fits the JK Wrangler Rubicon (2007-2018)
- Forged cross with improved seals and a perma-lube design
- Inside snap ring, snap ring to snap ring 2.405in.
- OEM replacement with no lube channel
SKU: D/S5-7166X -
Dana 44 U-Joints
Dana Spicer Dana 30/35/44 Heavy Duty Axle U-Joint – 5-760X
- Dana Spicer 5-760X heavy duty axle U-joint for Dana 30, 35 and 44 axles
- Cup size 1.188 in, snap ring to snap ring 2.188 in
- Inside snap ring, perma-lube improved seals
- Not lubeable, highway rated, O.E.M. replacement
SKU: D/S5-760X
The joint that steers and drives
On a solid front axle with locking hubs or full-time 4WD, the axle shaft is split into an inner and outer piece joined by a universal joint that lives inside the steering knuckle. Every time the wheel turns, the joint flexes, and in four-wheel drive it also carries torque. Mud, water and the heat of a long trail day attack it, and a failed front axle U-joint can take the knuckle, hub and ball joints with it. The joints here are sized by cap diameter and width, which correspond to the axle: 1.062 inch caps on the 260 series for the Dana 30 and small Dana 44, 1.188 inch caps on the 760 series for the Dana 30, 35 and 44 with the larger shafts, 1.375 inch caps on the Dana 60 and AAM 9.25 front axles.
Picking the right series
- 5-260X: Dana Spicer's joint for the Dana 30 and the small-shaft Dana 44, 1.062 inch caps, 2.188 inch snap ring to snap ring. Crown's 8126637BC is the factory equivalent for the XJ, CJ5, CJ7, Comanche, Scrambler and YJ.
- 5-760X: the 1.188 inch cap joint for later Dana 30s and the Dana 44, also 2.188 inch wide. Crown's 8126638SP covers the JK, TJ, YJ, XJ, ZJ and Wagoneer with the same caps.
- 5-7166X: the JK Rubicon Dana 44 joint at 2.405 inches snap ring to snap ring. It does not interchange with the 760 series.
- Dana 60 and AAM 9.25: 1.375 inch caps, used on Ford, Dodge and GM three-quarter and one-ton trucks. The SPL55-3X replaces the discontinued 5-806X.
Measure the old joint's cap diameter and overall width, or identify the axle from its cover shape and tag, before choosing. The same model Jeep used both 260 and 760 series depending on year.
Sealed, greaseable or extreme duty
Factory replacement joints from Dana Spicer and Crown are mostly non-greaseable, permanently lubricated units with improved seals, often described as perma-lube. They have a solid cross with no grease channel, which makes them stronger than a greaseable joint of the same size, and they suit most trail Jeeps. Greaseable joints, like the Alloy USA extreme-duty Dana 44 joints with a Zerk in each cap, let you flush water out after a wet trip, which matters if you ford streams regularly, but the grease passages reduce cross strength slightly. Extreme-duty or X-joint designs from Alloy USA and CTM Racing use forged caps and needle bearings or bushings for Jeeps on 37 inch tires and lockers, where the stock joint is the fuse. Keep in mind that making the joint stronger moves the failure point to the axle shaft or the knuckle, so upgrade in balance.
Replacement tips
Replacing a front axle U-joint means pulling the hub, bearing and axle shaft, so inspect the unit bearing, ball joints and axle seals while everything is apart. Use a press or a ball joint press adapter rather than a hammer, support the yoke ears evenly, and install the snap rings fully. Grease greaseable joints until fresh grease purges every cap seal, and check the shaft runs true before reassembly. Torque the hub bolts and axle nut to the manufacturer's specification. Steering and drivetrain parts affect safety, so if you are not equipped to press joints, have a shop do it. Confirm the joint matches your axle and year before choosing.
Related guides
- Chromoly vs Stock Dana 44 Shafts: When to Upgrade
Popular Front Axle U-Joints brands
Front Axle U-Joints FAQ
How do I know if a front axle U-joint is bad?
Signs are a clicking or popping noise while turning in four-wheel drive, a vibration that appears only with the front axle engaged, rust-colored dust around the caps, and visible play when you grab the axle shaft and twist with the wheel off. Caps that have spun in the yoke leave bright witness marks.
Are the 260 and 760 series joints interchangeable?
No. They have the same overall width but different cap diameters, 1.062 and 1.188 inches, and the yoke bores are machined for one or the other. Measure the old joint's caps or identify your axle shaft before choosing, since Jeeps of the same model used both over the years.
Should I choose a greaseable or non-greaseable joint?
A non-greaseable solid cross is stronger and maintenance free, which suits most trail use. A greaseable joint lets you purge water after crossings and extends life in wet conditions at a small cost in strength. Heavy-tire rigs often choose a forged extreme-duty joint instead.
Do I need to replace both front axle U-joints at once?
They see the same miles and conditions, so when one fails the other is usually close behind. Replacing both while the hubs are apart saves doing the job twice and keeps the axle balanced. Inspect the unit bearings and ball joints at the same time.
