Overview
The Rubicon Express RE2035 is a weld-on drop position shock mount for the rear of the Jeep Wrangler (TJ), 1997 to 2006. It is built to be stronger than the factory mount while keeping a similar shape.
The mount is a weld-on drop position shock mount for the rear of the Jeep Wrangler TJ from 1997 to 2006. It lets the rear shock sit lower so it clears the coil spring cup after the pinion has been rotated upward for CV drive shafts. It is sold as a pair in bare steel and must be welded in place.
Key features
- Drop style shock mount
- Similar to factory mounts, but stronger
- Repositionable rear shock mounting
- Clears the coil spring cup after pinion rotation
- Bare steel, sold as a pair
Rear suspension geometry
Rear shock placement affects how the suspension controls axle movement, so a drop mount changes the shock’s angle and travel. On a TJ, the shock has to clear the coil spring cup once the pinion has been rotated, and a mount set in the wrong place can bind the shock or limit compression. Check the layout with the axle at ride height and again under load.
Factory mounts are designed for stock geometry, so a repositioned mount may need a different shock length or eyelet. Inspect the shock bushings, the spring cup, and the rear axle housing for wear, since changes in geometry can increase stress on these parts. Recheck weld joints after the first trail runs, and retorque the shock hardware periodically.
- Confirm pinion rotation before welding
- Check shock clearance at full compression
- Inspect spring cups for cracks over time
Specifications
| Brand | Rubicon Express |
|---|---|
| Part number | RE2035 |
| UPC | 614901440010 |
| Mount type | Drop position, weld-on |
| Location | Rear |
| Finish | Bare steel |
| Sold as | Pair |
| Fitment | Direct fit for the 1997 to 2006 Jeep Wrangler TJ. |
Vehicle fitment
The mount is for the Jeep Wrangler (TJ) from 1997 to 2006, as named in the product title. It is intended for builds where the pinion has been rotated upward to fit CV drive shafts.
Confirm your vehicle’s year, model and trim before ordering, and check that your rear axle setup needs the drop position.
Installation notes
Welding is required. Check the mount position against the coil spring cup before welding, so the shock clears the cup once the pinion is rotated.
