Poison Spyder Upper Coil Over Mounts – 14-51-010

Poison Spyder Customs

Shop Poison Spyder Customs Shock Mounts on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Front upper coilover mounts in bare steel for builder projects, designed for Daddy Longlegs
  • Made from 3/16-inch plate steel for shocks with a 2-inch diameter body
  • Designed for full-width axles; upper tabs hold the shock bolt in double shear
  • Builder component with no installation instructions; welding required; UPC 614901736328

Description

Overview

The 14-51-010 is a set of front upper coilover mounts in bare steel, sold as one front upper mount. It is built for coilover shocks with a 2-inch diameter shock body. The mounts are CNC laser cut and brake-formed from 3/16-inch plate steel.

The upper tabs hold the shock bolt securely in double shear. The mounts are designed for full-width axles, because they lean outboard from the frame rail somewhat. Welding is required to fit them.

These mounts are built for owners with the fabrication skills to design and build their own coilover conversion. No technical support is offered for the product. The mounts save time for a builder who is comfortable measuring and fabricating, but they do not replace the design work.

The lower coilover mounts on the axle, the suspension link mounts and the shocks are not included, so the builder must design and build them. Mount geometry depends on the frame, axle and shock setup, so the lower mounts must match that layout.

Key features

  • Front upper mount for coilover shocks with a 2-inch diameter body
  • CNC laser cut and brake-formed 3/16-inch plate steel
  • Upper tabs hold the shock bolt in double shear
  • Designed for full-width axles
  • Bare steel, welding required
  • Builder component with no installation instructions

Planning a builder coilover

A coilover conversion depends on the relationship between the frame, axle, shock and mount. Small changes in mount position change shock angle and travel, so fit each part before deciding on final placement. Measure twice, then tack the mount in place for a test.

Upper mounts carry strong loads at the shock bolt, so weld quality matters. Clean the metal before welding, plan the weld sequence to limit heat distortion, and check the mount for flex after the first drives. Bushings and shock hardware should be checked on a regular schedule.

Builders often finish the lower mount and suspension links together, since both affect the same geometry. Test the whole setup at full droop and full compression before the Jeep sees trail use.

  • Test-fit before final welding
  • Clean metal well before welding
  • Check shock bolt and tabs after trail use
  • Plan lower mounts with the upper mount

Specifications

Brand Poison Spyder Customs
Part number 14-51-010
UPC 614901736328
Position Front upper mount
Material 3/16-inch plate steel
Shock body 2-inch diameter
Axle type Full-width axles
Finish Bare steel
Installation type Welding required
Instructions None included

Vehicle fitment

The mount is designed for full-width axles. Confirm fit for your Jeep’s frame and axle before ordering, and check the mount position against your build.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Welding is required, and no installation instructions are included. The builder must confirm the mount position against the frame and full-width axle, and must design the lower coilover mount and the suspension link mounts. Poison Spyder’s advice is that only experienced fabricators take this on.

What’s included

One front upper coilover mount in bare steel.

Not included: the lower coilover mounts on the axle, the suspension link mounts, the shocks and any installation instructions.

SKU: PSC14-51-010 Category:

Specification

Shipping weight 15.00 lbs
Package dimensions 20.00 × 10.00 × 7.00 in
brands

Questions & Answers

Is the 14-51-010 mount a complete coilover system?

No. It is only the front upper mount. The lower coilover mounts on the axle and the suspension link mounts are not included, so the builder must design and build them.

Are these mounts for full-width axles?

Yes. The mounts are designed for full-width axles because they lean outboard from the frame rail somewhat. Check the mount position against your frame and axle before welding.

What shock body diameter does the mount take?

The mount is designed for coilover shocks with a 2-inch diameter shock body, and its upper tabs hold the shock bolt in double shear.

Do these mounts need welding?

Yes. Welding is required to fit the mounts. No installation instructions are included, so the builder should plan the weld positions and fabrication steps in advance.

Should the upper mount be checked before welding?

Yes. Test-fit the mount with the shock, the frame and the axle at ride height before any weld is made. Recheck shock travel and clearance, since small position changes can affect the whole coilover setup.
