Russell Performance Street Legal Brake Line Assembly

Russell Performance

Shop Russell Performance Brake Hoses on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Street legal brake line assembly, three lines per kit
  • Two front hoses and one rear hose, braided stainless steel
  • Direct bolt-on, with hardware and fittings included
  • Lifted application, 2 to 4 inches; part number 695920

Description

Overview

The Russell Performance 695920 is a street legal brake line assembly with braided stainless steel hoses and zinc-plated hose ends. It is a direct bolt-on kit for lifted vehicles, and its hoses are designed to meet DOT MVSS-106 requirements for street driven vehicles.

The kit fits vehicles with disc front brakes and drum rear brakes. It covers lifted applications from 2 to 4 inches, including a 4 inch lift.

Key features

  • Braided stainless steel hoses
  • Zinc-plated hose ends
  • Factory assembled for easier installation
  • Three lines per kit: two front hoses and one rear hose
  • Direct bolt-on with hardware and fittings included
  • Russell states DOT MVSS-106 compliance for street driven vehicles

Inspecting brake lines over time

Brake hoses flex every time the suspension moves, and on a lifted vehicle they often travel a longer path to the caliper. Over time the rubber or braided sleeve can chafe against frame edges, suspension arms or tire clearance points. Routing matters: keep hoses clear of moving parts and heat sources, and leave enough slack for full suspension travel without pulling on the fittings. Braided stainless sleeves resist abrasion better than plain rubber, but they still need a visual check.

During routine service, look at each hose end for seepage, cracked sleeves and crimp damage, and check that fittings are snug without being overtightened. A soft pedal or spongy feel after a hose change usually points to trapped air, so bleed the system thoroughly. Brake fluid absorbs moisture over time, so keep the reservoir sealed and replace the fluid on your vehicle’s service schedule.

  • Look for fluid seepage at every fitting
  • Keep hoses clear of springs and sway bar links
  • Recheck clearance after any suspension change

Specifications

Brand Russell Performance
Part number 695920
UPC 87133959207
Lines per kit 3 (two front, one rear)
Hose material Braided stainless steel
Hose ends Zinc-plated
Lift application 2 to 4 inches (lifted)
Brake type Disc front, drum rear
Standard DOT MVSS-106 for street driven vehicles

Vehicle fitment

The kit’s vehicle details are a lifted range, disc front and drum rear brakes, with no model years.

Vehicles at stock height or with other brake layouts are not covered by the stated details. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Check that the two front hoses and one rear hose match your disc front and drum rear setup before installing. The kit includes the hardware and fittings needed for a direct bolt-on installation. Bleed the brakes after the hoses are replaced to clear air from the lines.

What’s included

Two front hoses, one rear hose, and the hardware and fittings needed for installation.

SKU: RUS695920 Category:

Specification

Shipping weight 1.08 lbs
Package dimensions 8.00 × 6.00 × 2.00 in
brands

Questions & Answers

Does the kit include front and rear hoses?

Yes. The kit has three lines: two front hoses and one rear hose, with the hardware and fittings included. Confirm the layout matches your brakes before installing.

What lift height is this kit for?

The kit is built for a 4 inch lift and covers lifted applications from 2 to 4 inches. Confirm your lift height before ordering.

Is this kit street legal?

Yes. The hoses meet DOT MVSS-106 requirements for street driven vehicles, and the kit is 50 states legal. Check local rules if your vehicle is registered elsewhere.

Does the kit fit disc and drum brakes?

Yes. It fits disc front brakes and drum rear brakes, so confirm your vehicle has that brake layout before ordering.

How often should brake lines be inspected?

Inspect them at each tire rotation or brake service. Look for leaks, cracked or swollen sleeves, chafing against the frame or suspension, and damaged fittings. Replace any hose that shows wear, and recheck the routing after any lift or suspension change.
