Overview
The Fab Fours DR10-N2450-1 is a black powder coat, one-piece winch mount for 2003–2010 and 2011–2018 Dodge Ram 2500 and 3500 trucks. It is built for the factory (OE) bumper and fastens by slipping through the factory tow hook slots so the mount reaches the frame. Because it is fully welded, there are no brackets to bolt together.
It is a durable steel winch mount that adds strength at the front of the truck. The -1 suffix marks the black finish, and the -B version is bare steel.
Key features
- One-piece design, fully welded, with no brackets to bolt together
- Slips through the factory tow hook slots straight to the factory frame
- Built from 3/8 inch steel mounts
- Two-stage matte black powder coat finish
- Bare steel alternative with the -B suffix
- Made in the U.S.A.
Choosing a winch for Ram duty
Ram 2500 and 3500 trucks often carry heavier loads and tow more than lighter pickups, so the front-end recovery setup should be chosen carefully. Match the winch’s rated capacity to the truck’s weight and to the recoveries you expect. A winch that is too large for the front of the truck places more strain on the mount and frame.
The black powder coat protects the steel from moisture and road debris, but the finish can chip. Clean the mount after mud and salt exposure, and touch up chips before rust gets started. Pay particular attention to the welds, since they can trap moisture.
Before a trip, check the factory tow hook slots and frame contact points for corrosion or movement. Tighten any fasteners that hold the winch and fairlead, and check the winch cable for wear. Many owners replace the cable and hook hardware at the same time as the mount, so review them together.
- Match winch rating to truck weight.
- Touch up chips before rust starts.
- Check tow hook slots before each trip.
Specifications
| Brand | Fab Fours |
|---|---|
| Part number | DR10-N2450-1 |
| UPC | 5810106072 |
| Material | 3/8 inch steel mounts |
| Finish | Black, 2 stage matte black powder coat |
| Construction | One piece, fully welded |
| Fit type | Direct fit to OE bumper |
| Alternate finish | Bare steel (-B instead of -1) |
| Made in | U.S.A. |
Vehicle fitment
The manufacturer fitment list names four Ram entries: 2003–2010 Dodge Ram 2500 and 3500, and 2011–2018 Ram 2500 and 3500. Listed trims include Laramie, SLT, ST, Power Wagon and Tradesman, depending on the entry.
Ram 1500 models are not on this list. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Mounting uses the factory tow hook slots and the factory frame, and no drilling or welding is described. Confirm the winch you plan to use fits the mount before installing.
What’s included
One-piece winch mount with a black powder coat finish.
Not included: a winch. None is listed with this mount.
