Overview
The Mountain Off Road Enterprises Ford 8.8 Install Kit, part number 98500, is a complete installation kit for fitting a Ford 8.8 axle into a 1987-1995 Jeep Wrangler YJ. It covers the spring and shock mounting points the swap needs.
The kit includes 2 weld-on anti-wrap spring mounts for the housing, 4 U-bolts, 2 U-bolt plates and 2 weld-on shock mounts. All of the hardware is unpainted, so it is ready for your own finish after fitting.
Key features
- Complete kit for a Ford 8.8 rear axle in a YJ
- Anti-wrap style spring mounts
- Four U-bolts with two U-bolt plates
- Weld-on shock mounts
- Unpainted hardware
Planning the axle swap
An axle swap changes the handling, ground clearance and steering geometry of the vehicle, so plan the whole setup before welding. The spring mounts set the pinion angle indirectly through the spring pack, which means the springs and shackles need to be chosen with the mounts in mind. Measure the housing and the new springs before drilling anything.
Weld-on brackets need clean, square surfaces on the housing, and the work is easier to control when the axle is on a stand. Heat can warp a thin housing, so keep the welds short and let the axle cool between passes. Mark the mount positions with the axle under the vehicle, not on a bench.
After the swap, check the U-bolts for tightness after the first drives, and inspect the welds for cracks. Shock mounts take high loads on the trail, so look at them after rough outings.
- Clean the housing before welding
- Check U-bolts after early drives
- Inspect welds after rough trail use
Specifications
| Brand | Mountain Off Road Enterprises |
|---|---|
| Part number | 98500 |
| UPC | 815572021410 |
| Axle | Ford 8.8 |
| Axle location | Rear |
| Spring mounts | 2 weld-on anti-wrap style |
| U-bolts | 4 |
| U-bolt plates | 2 |
| Shock mounts | 2 weld-on |
| Finish | Unpainted |
Vehicle fitment
The kit is for installing a Ford 8.8 rear axle in a 1987-1995 Jeep Wrangler YJ.
It is built for the YJ generation and is not intended for the TJ or JK. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The spring and shock mounts are weld-on style, so the housing work calls for welding equipment. Welding brackets onto an axle housing should be done by someone experienced with axle work.
What’s included
The kit includes 2 weld-on anti-wrap spring mounts, 4 U-bolts, 2 U-bolt plates and 2 weld-on shock mounts.
Not included: the Ford 8.8 axle itself, plus the springs and shocks that the mounts hold.
