Overview
Part number FOX985-24-239 is a rear reservoir shock that fits 2020–2026 Chevrolet Silverado 2500 HD and 3500 HD and GMC Sierra 2500 HD and 3500 HD trucks. Its aluminum body is clear anodized and metal-impacted, which helps it shed heat.
The external reservoir adds oil and nitrogen capacity, and it gives the shock a race-style look. The reservoir clamp is black anodized and CNC machined from 6061-T6 aluminum. The damping piston is a high flow design with matched valving.
The external reservoir sits off the main body and holds extra oil and nitrogen. That added capacity supports steady damping on long, rough routes and under heavy loads, which matters most on heavy-duty trucks that carry larger payloads and tow often.
Key features
- External reservoir for extra oil and nitrogen capacity.
- Metal-impacted, clear anodized aluminum body that sheds heat.
- Black anodized reservoir clamp CNC machined from 6061-T6 aluminum.
- High flow damping piston matched with application-specific valving.
- Eyelet mounts at both ends with a 2.0 in body diameter.
Reservoir shocks under heavy duty use
Heavy-duty trucks run higher loads and more towing than light-duty pickups, so the rear shocks work harder. A reservoir shock keeps extra oil and gas away from the main body, which can help the damping stay steadier over long hauls. Owners who tow often or run gravel and rough fire roads will notice the difference in how the back of the truck settles.
Reservoir shocks take up more space than a standard shock, so check clearance around the reservoir before tightening the mounts. Inspect the reservoir hose, clamp and body for wear or grit after off-road trips. Keeping the clamp snug and the reservoir clean helps preserve the seals over time.
- Check clearance around the reservoir
- Inspect the clamp after rough trips
- Keep grit off the reservoir body
Specifications
| Brand | FOX |
|---|---|
| Part number | FOX985-24-239 |
| Shock series | 2.0 Performance Series |
| Position | Rear |
| Top mount | Eyelet |
| Bottom mount | Eyelet |
| Body diameter | 2.0 in |
| Shock type | Monotube with external reservoir |
| Body material | Clear anodized aluminum |
| Reservoir clamp | Black anodized 6061-T6 aluminum |
| Charge | Gas charged |
Vehicle fitment
It fits the 2020–2026 Chevrolet Silverado 2500 HD and 3500 HD and the 2020–2026 GMC Sierra 2500 HD and 3500 HD. Light-duty 1500 trucks are outside this fit.
Confirm your vehicle’s year, model and trim before ordering.
What’s included
One rear shock with its reservoir and the black anodized reservoir mounting clamp.
