Overview
The Crown Automotive 52000503 is a black rubber leaf spring bushing for the main eye of a leaf spring. It fits 1984–2001 Jeep Cherokee (XJ) models.
It has inner and outer steel sleeves and is non-greaseable. It is made for the main eye or front of the spring, so confirm the mounting point before fitting.
Key features
- Rubber body with inner and outer steel sleeves
- Main eye or front of spring application
- Non-greaseable design
- Black color
- Direct fit.
Main eye bushing wear
The main eye bushing carries the spring’s front pivot, so it takes both vertical load and side movement. As the rubber breaks down, the spring can shift at the eye and the front of the vehicle may feel loose or wander on the road. Clunks over bumps and uneven tire wear can both point to a worn bushing.
Replacing this bushing is easier with the spring removed from the vehicle, and the new bushing should sit square in the eye. Because the sleeves are steel, pressing them straight avoids damaging the rubber. Check the spring eye itself for cracks or distortion while the spring is off.
- Look for rubber that is cracked, split or bulging
- Check for play between the eye and the spring pin
- Inspect the spring eye for distortion while it is off
Specifications
| Brand | Crown Automotive |
|---|---|
| Part number | 52000503 |
| UPC | 848399012361 |
| Type | Rubber |
| Sleeves | Inner and outer steel |
| Service | Non-greaseable |
| Position | Rear |
| Color | Black |
| Fitment type | Direct fit |
Vehicle fitment
It fits the 1984–2001 Jeep Cherokee (XJ) in Base, Briarwood, Chief, Classic, Country, Laredo, Limited, Pioneer, SE and Sport trims.
Other Jeep models, including the Wrangler YJ, are not on this list.
Look over your year and trim against the entries above before you pick a bushing.
Installation notes
Replacing a main eye bushing usually means removing the spring, and a shop press or suitable bushing tool is typically needed to remove and fit the bushing. Support the axle on jack stands before loosening spring hardware.
What’s included
A leaf spring bushing with inner and outer steel sleeves.
Not included: The spring, shackle and other hardware are not included.
