Overview
The Baer Brakes D2223 is a front brake pad set from the Baer Claw line for the 2019–2026 Ram 2500, the 2019–2026 Ram 3500 and the 2019–2020 Ram 4000 trucks. Each set holds 4 pads for the front axle and carries FMSI number D2223 along with Baer part number D2223.
The Claw pads are presented as OE replacement pads with steady wear and little noise or dust, which suits everyday driving rather than track use. The written description names a premium high friction ceramic compound, but the specification table lists semi-metallic friction material, so verify the material before installation.
Key features
- OE replacement front pads with steady wear and little noise or dust
- Premium high friction compound with low rotor wear and long pad life
- Road-going comfort suited to daily drivers
- Stainless steel abutment hardware and anti-rattle parts come with most applications
- Slotted face, mechanical wear sensor and attached wear indicator
- 4 pads per set, for the front axle
Front brakes under load
Front brakes carry a large share of the stopping work on many heavy-duty trucks, especially when a load or trailer sits behind them. That makes the front pads, rotors and caliper hardware worth inspecting as a set. Look for scoring or heat marks on the rotor face, and check that the caliper slides move freely before the new pads go in, because sticking slides wear pads unevenly.
Friction material matters most under repeated braking. Ceramic compounds tend to run quieter and leave less dust, while semi-metallic compounds handle heavy use and heat with more bite. Match the material to how the truck is driven, and keep the old pads’ shape in mind so any shim or clip change is noticed before fitting.
- Replace worn abutment clips with the set’s own parts
- Check brake hose and bracket for rust before reassembly
- Bed in pads gently before towing
- Recheck caliper bolt torque after the first drive
Specifications
| Brand | Baer Brakes |
|---|---|
| Part number | D2223 |
| FMSI number | D2223 |
| UPC | 810215398201 |
| Supplied as | Set |
| Pads per set | 4 |
| Axle | Front |
| Friction material | Semi-metallic |
| Grade type | Premium |
| Emission code | 6 |
| Backing plate color | Black |
| Slotted | Yes |
| Pad wear sensor | Included, mechanical type |
| Wear indicator attached | Yes |
| Pad shims included | Yes |
| Abutment clips included | Yes |
| Mounting hardware included | No |
| Brake lubricant included | No |
| Country of origin | USA |
Vehicle fitment
The manufacturer fitment list names the 2019–2026 Ram 2500, the 2019–2026 Ram 3500 and the 2019–2020 Ram 4000 for the front axle.
This set is for the front axle only; rear-axle Ram pads are a separate part. Before buying, make sure your truck’s year, model and trim fall within the coverage above.
Installation notes
Position the abutment clips and pad shims as supplied when fitting the pads. Front brakes take most of the stopping load on many heavy-duty trucks, so inspect the caliper bracket for rust and confirm the slide pins move freely. Bed in the new front pads gently before towing, and check pedal feel at low speed before normal driving. Hardware for the caliper bracket and brake lubricant must be obtained separately.
What’s included
4 front pads with pad shims, abutment clips and a mechanical pad wear sensor with its indicator.
Not included: mounting hardware and brake lubricant.
