Overview
The ReadyLift 69-5175 is a 3-inch SST suspension lift for the Toyota Tundra, supplied with a 1.0-inch rear block. It fits 2007 to 2021 Tundra models in the 1794 Edition, Base, Limited, Nightshade, Platinum, SR, SR5, TRD Pro and Trail versions. It covers TRD, SR5 and Rock Warrior trucks in Crew Max, Double Cab and Standard Cab bodies.
Some TRD Tundras have less factory rake than non-TRD models. The 1.0-inch rear block helps most TRD, SR5 and Rock Warrior trucks reach an approximately near-level stance. The kit accommodates tires up to 35 inches in diameter while keeping the stock ride and handling.
Key features
- 3 inches of front lift
- Powder coated steel strut extension
- Front differential drop spacers
- Sway bar spacers
- Skid plate spacers
- New 1-inch rear lift block
- Tires up to 35 inches in diameter
Setting rake on a Tundra lift
Rake is the difference between front and rear height, and it shapes how the truck sits on the road. Trucks with a stock rake often look uneven after a front lift alone, which is why the rear block is part of the setup. Measure front and rear ride height on level ground before and after the job so you know the change.
Load changes the rake too. A bed full of gear or a trailer hitch can shift rear height, so set the lift with normal payload in mind. Tire size also affects height, and larger tires can change how the stance looks at the wheel wells.
- Measure front and rear height on level ground
- Check rake again after loading the bed
- Recheck fender clearance after tire changes
- Inspect the rear block bolts after the first drives
Specifications
| Brand | ReadyLift |
|---|---|
| Part number | RDY69-5175 |
| Front lift | 3 inches |
| Rear lift | 1.0 inch block |
| Front components | Powder coated steel strut extension, differential drop spacers, sway bar spacers |
| Skid plate | Skid plate spacers |
| Tire size | Up to 35 inches |
| Drive type | The kit works with 2WD and 4WD Tundras. |
| Fitment type | Direct fit |
Vehicle fitment
It fits 2007 to 2021 Toyota Tundra models in the 1794 Edition, Base, Limited, Nightshade, Platinum, SR, SR5, TRD Pro and Trail versions.
The rear lift uses the supplied 1.0-inch block. Confirm the 2020 and 2021 rear lift setup before ordering.
Installation notes
The 3-inch system needs no cutting or strut spring pre-loading and installs with the heavy-duty hardware included. Follow the step-by-step instructions supplied with each kit. The strut extension and differential drop bracket change the front geometry, so check the alignment afterward.
What’s included
The kit includes a powder coated steel strut extension, front differential drop spacers, sway bar spacers, skid plate spacers and a new 1-inch rear lift block.
