Fabtech 4 Inch Lift Kit w/Stealth Shocks – FTS21184

Fabtech

Shop GMC Sierra 2500 HD Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Lists the 2011–2015 Silverado and Sierra 2500 HD and 3500 HD
  • 4-inch lift with tubular Uniball upper control arms
  • Front differential relocated to keep CV angles proper
  • 1/4-inch steel skid plate and rear 1 1/2-inch lift block
  • Stealth monotube shocks included

Description

Overview

The Fabtech FTS21184 is a 4-inch lift system with Stealth monotube shocks for the 2011–2015 Chevrolet Silverado 2500 HD and 3500 HD and the 2011–2015 GMC Sierra 2500 HD and 3500 HD. The front keeps the factory coilover shocks on a steel spacer system, and the rear uses a 1 1/2-inch lift block with U-bolts.

The stock upper control arms are replaced with tubular Uniball arms made from 0.120 wall 4130 chromoly, with a 1.50-inch OD and 1-inch FK stainless PTFE Uniballs. The front differential is relocated to keep CV angles proper at the new height, and a 1/4-inch thick steel skid plate guards the front. This kit is made for factory aluminum suspension vehicles, so confirm fit for your vehicle’s year, model and trim before ordering.

Key features

  • 4-inch lift height
  • Tubular Uniball upper control arms
  • Factory coilover shocks kept on a steel spacer system
  • Front differential relocated
  • 1/4-inch steel skid plate
  • Rear performance shock absorbers

Choosing the right setup

Factory suspension type matters with this kit. Aluminum front suspension and steel front suspension are different builds, so confirm which one your truck has before buying parts. A coilover spacer system keeps the factory shock and spring assembly in place, which keeps the front end closer to the original setup than a full coilover conversion would.

Shock mounts and shock bodies see new angles after a lift, so keep them clean and check for leaks during the first few weeks of driving. A rear lift block shifts the axle position, which makes U-bolt torque worth rechecking early. Because the front differential moves, driveline angles deserve a look once the kit is installed and the truck has settled.

  • Check U-bolt torque after the first few drives
  • Look over the coilover spacers for wear
  • Inspect the CV boots for stretch at the new height

Specifications

Brand Fabtech
Part number FTS21184
UPC 674866091078
Lift height 4 inches (range 3 to 4.99 inches)
Suspension type Lift spindle
Upper control arm tubing 0.120 wall 4130 chromoly, 1.50-inch OD
Uniballs 1-inch FK stainless PTFE
Skid plate 1/4-inch thick steel
Rear lift 1 1/2-inch lift block and U-bolts
Shocks Stealth monotube shocks; performance rear shock absorbers
Tire and wheel fit 33/12.50R17 on 17×8, 275/65R18 on 18×8, 295/55R20 on 20×9

Vehicle fitment

It is offered for the 2011–2015 Chevrolet Silverado 2500 HD and 3500 HD and the 2011–2015 GMC Sierra 2500 HD and 3500 HD.

The system only fits factory aluminum suspension vehicles. It is not for models with Factory AutoRide shocks, all-wheel drive models or standard cab trucks. Confirm fit for your vehicle’s year, model and trim before ordering.

Installation notes

Check whether the factory front suspension is the aluminum or steel version before fitting, since this kit is built for the aluminum type. The OEM wheel and tire cannot be used with this kit.

What’s included

Tubular Uniball upper control arms, the front coilover spacer system, the front differential relocation parts, the 1/4-inch steel skid plate, the 1 1/2-inch rear lift block with U-bolts and Stealth monotube shocks.

SKU: FABFTS21184 Category:

Specification

Shipping weight 145.00 lbs
Package dimensions 25.60 × 23.50 × 12.10 in
brands

Fitment

VehicleYearsTrims
Chevrolet Silverado 2500 HD2011–2015High Country, LT, LTZ, WT
Chevrolet Silverado 3500 HD2011–2015High Country, LT, LTZ, WT
GMC Sierra 2500 HD2011–2015Base, Denali, SLE, SLT, WT
GMC Sierra 3500 HD2011–2015Base, Denali, SLE, SLT, WT

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the FTS21184 fit a 2013 Silverado 2500 HD?

Yes. It fits 2011–2015 Chevrolet Silverado 2500 HD trucks, so a 2013 truck falls within the covered years. The kit is for factory aluminum suspension, so confirm your front suspension type before ordering.

What tires does the FTS21184 use?

The kit runs 33/12.50R17 tires on 17x8 wheels, 275/65R18 on 18x8 and 295/55R20 on 20x9 wheels, with minor trimming on all three. The OEM wheel and tire cannot be used with this kit.

Are shocks included with the FTS21184?

Yes. The kit includes Stealth monotube shocks along with performance rear shock absorbers. Both come with the kit, so no separate shock purchase is needed.

How do I tell whether my truck has aluminum or steel front suspension?

Check the front suspension components and any stamped markings on the parts before ordering. A dealer can also confirm the suspension type from your VIN. Matching the suspension type to the kit prevents fitment problems later.
