Overview
The Rough Country N3 rear lift strut R/C23306_A is a nitrogen-charged rear strut for 2019–2023 Ford Ranger pickups with a 4 to 6 inch lift. It uses eyelets at the top and bottom and is sold as a pair.
Rough Country classifies this unit as a lift strut, so it is a strut-type unit rather than a standard shock. Its extended length is 25.98 in and its compressed length is 15.74 in. It uses a 35mm piston, an 18mm chrome-hardened piston rod and a 54mm body, with ten-stage variable valving. Lift struts are sized to a specific lift height, so the 4 to 6 inch range should match the lift on your truck.
Key features
- Lift strut design with nitrogen charge
- 10-stage variable valving
- 35mm piston and 18mm chrome-hardened piston rod
- 54mm shock body designed to shed heat faster
- Rated to 36kN tensile strength
- Spring-loaded piston rod seal and rubber bushings
- Military spec damper fluid
Lift struts and driveline angles
A lift strut replaces a shock at a greater height and also takes part in holding the axle in position. Raising the rear of the truck changes the angle of the driveshaft, so the struts and the driveline have to be considered together. A strut that is sized for a specific lift keeps the axle geometry closer to stock.
Installation is a good time to inspect the rear bump stops, control arm bushings and driveshaft u-joints. Worn parts can make a lifted truck vibrate or bind under load. Recheck the rear alignment after the first few drives, since small changes in ride height can shift the angles.
- Inspect driveshaft u-joints for play
- Check rear control arm bushings for wear
- Recheck rear alignment after the first drives
Specifications
| Brand | Rough Country |
|---|---|
| Part number | R/C23306_A |
| Product line | N3 Performance |
| Shock type | Lift strut |
| Position | Rear |
| Lift height | 4-6 in. |
| Top mount | Eyelet |
| Bottom mount | Eyelet |
| Extended length | 25.98 in |
| Compressed length | 15.74 in |
| Body diameter | 54mm |
| Piston | 35mm |
| Piston rod | 18mm chrome-hardened |
| Charge | Gas charged, nitrogen |
| Valving | 10-stage variable |
| Tensile strength | 36kN |
| Fluid | Military spec, rated to -40 C |
| Finish | Metallic silver paint |
| Warranty | 3-year warranty |
| Sold as | Pair |
Vehicle fitment
It is a fit for the 2019–2023 Ford Ranger across its Lariat, XL and XLT models. It is sized for a rear lift of 4 to 6 inches.
The list covers the 2019 to 2023 Ranger only, so the earlier Ranger generations from 1983 to 1997 and the 1998 to 2018 models are not included. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
A lift strut at this height changes the rear ride height, so check the rear alignment and the driveline angles after installation. Confirm the eyelet mounts match your existing rear hardware.
What’s included
Sold as a pair, with one rear strut for each side.
