Overview
The Pro Comp 89 Series Kore in 17×9 inches is a cast aluminum spoke wheel in flat black with a 5 on 4.5 bolt pattern. Part number PXA7089-7965 identifies this version, which Pro Comp Alloy Wheels sells in its 89 Series for trucks and SUVs that run wider wheels and need clearance behind the brake assembly.
This wheel carries a -6 offset, which moves the mounting face toward the back of the rim, so it sits a little farther out than a zero-offset wheel. The 4.75 backspacing is the distance from the mounting face to the back edge of the rim, which sets how much room the wheel needs toward the axle and brakes. Its 83 center bore centers the wheel on the hub.
Key features
- Cast aluminum spoke wheel in flat black
- 17 inch diameter with a 9 inch width
- 5 on 4.5 bolt pattern
- 83 center bore for hub centering
- -6 offset and 4.75 backspacing
- Pro Comp 89 Series styling
Choosing a wider rim
A 9 inch wide rim supports a wider tire footprint, but the tire’s rated rim width must match the wheel. A tire that is too narrow or too wide for its rated range can bead poorly and handle unpredictably. Check the sidewall and load rating before mounting, and make sure the wider profile still clears the fender at full lock.
Changing wheel width often changes the tire’s position relative to the suspension, so think about the whole setup. Wider tires can push the outer edge past the fender, and a negative offset increases that effect. Spacers are not a substitute for correct offset and should be avoided unless clearance requires them.
- Confirm the tire’s rim width range
- Check clearance at full steering lock
- Verify clearance at full suspension compression
Specifications
| Brand | Pro Comp Alloy Wheels |
|---|---|
| Part number | PXA7089-7965 |
| Series | 89 Series Kore |
| Construction | Aluminum |
| Style | Spoke |
| Finish | Flat black |
| Diameter | 17 inches |
| Width | 9 inches |
| Bolt pattern | 5 on 4.5 |
| Center bore | 83 |
| Offset | -6 |
| Backspacing | 4.75 |
Vehicle fitment
Fit depends on the 5 on 4.5 bolt pattern and 83 center bore matching your hub. The -6 offset and 4.75 backspacing decide how the wheel clears the fender, brake caliper and steering parts. Confirm fit for your vehicle’s year, model and trim before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
A wider rim with a negative offset pushes the tire outward, so check fender clearance at full steering lock and under suspension compression. The 83 center bore must match the hub or be fitted with a hub-centric ring before the wheel is mounted. Confirm the 5 on 4.5 pattern on your hub before the lug nuts go on.
What’s included
One 17×9 aluminum wheel, part number PXA7089-7965. Check the lug hardware and center cap you need before mounting.
