Pro Comp 89 Series Kore, 17x9 Wheel with 5 on 4.5 Bolt Pattern – Matte Black – 7089-7965

Pro Comp Alloy Wheels

$215.87In stock
Buy on Amazon

See similar parts on Amazon

Price and availability as of Nov 18, 2026 9:40 AM MST, from Amazon.com, and subject to change. The Amazon listing has the current details.

Check out with your Amazon account. Amazon handles delivery and returns.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Pro Comp 89 Series Kore, 17×9 inch cast aluminum spoke wheel, part number PXA7089-7965
  • 5 on 4.5 bolt pattern, 83 center bore, -6 offset, 4.75 backspacing
  • Flat black finish
  • No vehicle fitment is listed; check bolt pattern and offset first

Description

Overview

The Pro Comp 89 Series Kore in 17×9 inches is a cast aluminum spoke wheel in flat black with a 5 on 4.5 bolt pattern. Part number PXA7089-7965 identifies this version, which Pro Comp Alloy Wheels sells in its 89 Series for trucks and SUVs that run wider wheels and need clearance behind the brake assembly.

This wheel carries a -6 offset, which moves the mounting face toward the back of the rim, so it sits a little farther out than a zero-offset wheel. The 4.75 backspacing is the distance from the mounting face to the back edge of the rim, which sets how much room the wheel needs toward the axle and brakes. Its 83 center bore centers the wheel on the hub.

Key features

  • Cast aluminum spoke wheel in flat black
  • 17 inch diameter with a 9 inch width
  • 5 on 4.5 bolt pattern
  • 83 center bore for hub centering
  • -6 offset and 4.75 backspacing
  • Pro Comp 89 Series styling

Choosing a wider rim

A 9 inch wide rim supports a wider tire footprint, but the tire’s rated rim width must match the wheel. A tire that is too narrow or too wide for its rated range can bead poorly and handle unpredictably. Check the sidewall and load rating before mounting, and make sure the wider profile still clears the fender at full lock.

Changing wheel width often changes the tire’s position relative to the suspension, so think about the whole setup. Wider tires can push the outer edge past the fender, and a negative offset increases that effect. Spacers are not a substitute for correct offset and should be avoided unless clearance requires them.

  • Confirm the tire’s rim width range
  • Check clearance at full steering lock
  • Verify clearance at full suspension compression

Specifications

Brand Pro Comp Alloy Wheels
Part number PXA7089-7965
Series 89 Series Kore
Construction Aluminum
Style Spoke
Finish Flat black
Diameter 17 inches
Width 9 inches
Bolt pattern 5 on 4.5
Center bore 83
Offset -6
Backspacing 4.75

Vehicle fitment

Fit depends on the 5 on 4.5 bolt pattern and 83 center bore matching your hub. The -6 offset and 4.75 backspacing decide how the wheel clears the fender, brake caliper and steering parts. Confirm fit for your vehicle’s year, model and trim before ordering.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

A wider rim with a negative offset pushes the tire outward, so check fender clearance at full steering lock and under suspension compression. The 83 center bore must match the hub or be fitted with a hub-centric ring before the wheel is mounted. Confirm the 5 on 4.5 pattern on your hub before the lug nuts go on.

What’s included

One 17×9 aluminum wheel, part number PXA7089-7965. Check the lug hardware and center cap you need before mounting.

SKU: PXA7089-7965 Categories: ,

Questions & Answers

What bolt pattern does the Pro Comp PXA7089-7965 wheel use?

It uses a 5 on 4.5 bolt pattern with an 83 center bore. The lug count and spacing must match your hub, and the center bore should suit the hub diameter.

How wide is the Pro Comp 89 Series Kore 17x9 wheel?

It is 9 inches wide and 17 inches in diameter. It has a -6 offset and a 4.75 backspacing, and it is a flat black spoke design in cast aluminum.

Is this wheel a good match for a wheel with a different offset?

A -6 offset moves the mounting face toward the back of the rim, so the wheel sits farther out than a zero-offset version. Compare the -6 offset with your current wheel before swapping, since the tire will move outward.

Can a wider rim change how the tire wears?

It can. A wider rim changes the tire's footprint and sidewall flex, so tire pressure and alignment matter more. Check the tire's rated rim width before choosing one, and recheck toe after the first few drives.
