Pro Comp 6 Inch Lift Kit with ES3000 Shocks – K5067B

Pro Comp Suspension

Shop Toyota FJ Cruiser Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • The 6-inch Stage 1 kit fits the 2007–2009 Toyota FJ Cruiser.
  • Crossmember, steering knuckles and strut spacers at the front
  • Diff drop brackets, front sway bar spacers and bump stop extensions
  • Rear coil springs with ES3000 shocks named in the product name

Description

Overview

The Pro Comp K5067B is a 6-inch Stage 1 lift kit with ES3000 shocks for the 2007–2009 Toyota FJ Cruiser. The front uses a crossmember, steering knuckles and strut spacers, and the rear is lifted with coil springs.

Differential drop brackets, front sway bar spacers, bump stop extensions and brake line extension brackets are all part of the kit. The front shocks are re-used OEM units, so check the shock package before ordering.

Key features

  • 6-inch lift height from a Stage 1 kit
  • Front crossmember and steering knuckles
  • Strut spacers
  • Differential drop brackets
  • Front sway bar spacers and bump stop extensions
  • Brake line extension brackets and rear coil springs

Strut spacers and front geometry

Strut spacers raise the strut tower position, which changes camber and caster and can alter steering feel. Combined with steering knuckles and a front crossmember, the front end moves into a different geometry that should be measured rather than guessed. Tire wear at the front edges is a common early sign that the setup needs attention.

Differential drops lower the axle to reduce driveline angles that rise when front and rear heights differ. Angles that are too steep cause vibration and joint wear, so measure them after the install. Sway bar spacers and bump stop extensions change how the suspension reaches the end of travel, so check that they do not bind.

Strut top nuts and spacer hardware should be rechecked after the first few drives, since new fasteners settle. Inspect strut mounts yearly for cracks or play, and replace worn bushings before they affect alignment.

  • Driveline angle check after the lift
  • Brake line length at full travel
  • Retorque hardware after the first drives
  • Inspect strut mounts each year

Specifications

Brand Pro Comp Suspension
Part number K5067B
UPC 614901207415
Lift height 6 inch (lift height range 5 to 6.99 inches)
Lift kit stage Stage 1
Suspension type Knuckle
Front lift Crossmember, steering knuckles and strut spacers
Rear lift Coil springs
Front shocks Re-use OEM (the product name cites ES3000 shocks)

Vehicle fitment

Fitment covers 2007–2009 Toyota FJ Cruiser Base, TRD Special Edition and Trail Teams Special Edition trucks.

The list covers the 2007 through 2009 model years, so the 2010 and newer FJ Cruiser and the earlier Toyota trucks are not included. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

The strut spacers and steering knuckles alter the front geometry, so the alignment should be set and the driveline angles checked once the kit is in place.

What’s included

The kit includes the front crossmember, steering knuckles, strut spacers, differential drop brackets, front sway bar spacers, bump stop extensions, brake line extension brackets, and the rear coil springs.

SKU: EXPK5067B Category:

Specification

Shipping weight 217.35 lbs
Package dimensions 0.00 × 0.00 × 0.00 in
brands

Fitment

VehicleYearsTrims
Toyota FJ Cruiser2007–2009Base, TRD Special Edition, Trail Teams Special Edition

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the K5067B fit a 2010 FJ Cruiser?

No. The kit fits the 2007 through 2009 Toyota FJ Cruiser, so a 2010 model is outside the covered years. Check the model year before you order.

Are shocks included?

The front shocks are re-used OEM units, and the kit name also mentions ES3000 shocks. Check the shock package before placing an order.

Does it fit the TRD Special Edition?

Yes. The FJ Cruiser versions on the list are the Base, TRD Special Edition and Trail Teams Special Edition for the 2007 through 2009 model years.

Do strut spacer bolts need to be re-torqued?

Yes, check the strut top nuts and spacer hardware after the first few drives, since new fasteners can settle. Retorque to the factory torque specification for your model year.

Why would a diff drop be needed after a lift?

A diff drop lowers the differential to reduce driveline angles that rise when front and rear heights change. Angles that are too steep cause vibration and wear on the joints, so check them after installation.
