Overview
The Poison Spyder 13-18-010 Trail Cage is an eight piece bare steel kit that turns the factory roll bar of a 1987-1995 Jeep Wrangler YJ into a full roll cage. It is designed for owners who already have the factory roll bar and want to extend it rather than install a complete new cage.
The kit includes two Lower A-Pillars that run from the dash to the floor, two tubular upper A-Pillars that weld to the factory windshield bars, a dash bar, an upper windshield bar and two center spreaders that can be placed in several positions. The cage mounts at the windshield, the front gusseted A-Pillar, the factory door jamb mounts and the floor through the forward drain hole.
Key features
- Eight piece kit with two center spreaders that can be located in several positions
- Lower A-Pillars designed to avoid intruding into the dash or cutting into legroom
- Tubular components CNC bent and laser notched for fit
- Laser-marked reference numbers on each tube, for installation
- Works with all soft goods, factory and aftermarket tops
- Bare steel finish
Before welding the cage
A roll cage extension changes how the body and frame share crash loads, so weld quality matters more than speed. Prepare each weld area by removing paint, rust and mill scale back to clean metal. Use the laser marks to match pieces and fit every tube before welding, and keep the factory bar joints intact while you work.
Clearance deserves a plan before the first tack. Check how the center spreaders sit against seats, doors and any passenger, and confirm the dash bar will not interfere with gauges or wiring. Make sure the upper windshield bar lines up with the factory bars, and test-fit the soft top over the finished frame before final welding. Protect bare steel with a coating afterward.
- Weld areas cleaned to bare metal
- Spreader positions checked against seats and doors
- Soft top test-fit before final welds
Specifications
| Brand | Poison Spyder Customs |
|---|---|
| Part number | 13-18-010 |
| UPC | 614901724523 |
| Kit pieces | 8 |
| Tubing | 1.75 in x .120 wall DOM structural tubing |
| Finish | Bare steel |
| Installation type | Weld in |
| Soft tops | Works with all soft goods, factory and aftermarket |
Vehicle fitment
The kit is designed for the 1987-1995 Jeep Wrangler YJ and adds to the factory roll bar of those models.
This kit is designed for the YJ factory roll bar. Confirm fit for your vehicle’s year, model and trim before ordering.
Installation notes
Welding is required, and the kit arrives disassembled. The cage is secured at the windshield, the front A-Pillar, the factory door jamb mounts and the floor, so use the laser-marked reference numbers to match each piece. Have the welds on a roll cage checked by an experienced fabricator.
What’s included
Eight pieces: two Lower A-Pillars, two tubular upper A-Pillars, a dash bar, an upper windshield bar and two center spreaders.
Not included: the factory roll bar, which the kit is designed to extend.
