Overview
The Bilstein 24-010467 is a rear monotube gas charged shock absorber from the 4600 Series, with a 2 in body diameter, a yellow finish and boots included. It fits 1984-2001 Jeep Cherokee (XJ) models across trims from Base through Sport. Its lift height is 0 in, so it is a stock-height replacement with no lift or drop.
Bilstein says its gas charged monotube body moves heat from the oil out through the shock body, while a dividing piston lets the oil expand as it heats so foaming and viscosity loss stay low. The seamless extruded tube is built to a tight peak-to-valley tolerance and even wall thickness, and the piston head lets compression and rebound damping be tuned separately for ride comfort. The specifications list no reservoir, so the unit has no separate reservoir.
Key features
- Gas charged monotube with a patented heat transfer design.
- Dividing piston lets the oil expand, reducing aeration and viscosity loss.
- Extruded seamless tube for strength and consistent wall thickness.
- Separately tunable compression and rebound damping through the piston head.
- Boots included, with no separate reservoir.
Choosing a replacement shock
Rear shocks on older Jeep trucks and SUVs work hard over rough ground, and the damper is often replaced when the ride starts to feel loose or floaty after long use. A gas charged monotube design keeps the oil under pressure, which helps the damping stay steady when the shock warms up on long descents or repeated bumps. When choosing a replacement, look at the mounting style and the overall length at full extension, because a shock that is too long or too short will not seat properly or may bind the suspension.
Rear shocks are usually replaced in pairs so both sides damp the same way, and bushings and mounting hardware are worth inspecting at the same time. Look for oil residue on the body, a clunk over bumps, or uneven tire wear as signs the old unit has worn out. Keep the boots intact, since a torn boot lets grit reach the shaft seal.
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-010467 |
| UPC | 651860607528 |
| Shock series | 4600 Series |
| Type | Monotube, gas charged |
| Body diameter | 2 in |
| Reservoir | No |
| Boots included | Yes |
| Finish | Yellow |
| Position | Rear |
| Lift height | 0 in (lift/drop) |
| Fitment type | Direct fit |
Vehicle fitment
The manufacturer fitment list includes the 1984-2001 Jeep Cherokee (XJ) with Base, Briarwood, Chief, Classic, Country, Laredo, Limited, Pioneer, SE and Sport trims. The specifications describe this rear shock as a direct fit part, so use the XJ as the starting point for matching it to your vehicle.
The list does not include the Grand Cherokee ZJ or WJ, the Liberty KJ or the Wrangler. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Boots come with this shock, so check them for tears and secure seating when fitting it to the rear mount.
What’s included
A rear shock absorber with boots, as the specifications state. The specifications show no reservoir.
