Overview
The AIRAID Synthaflow air cleaner assembly 701-471 is a dry synthetic mesh OEM replacement filter with a 4 in. flange, a 6 in. base and a 9 in. length. It is washable, reusable and has a short flange.
The SynthaMax layer is a dry flowing synthetic layer that adds to filtration. The filter is covered by a Lifetime No-Hassle warranty and is made in the U.S.A.
Key features
- Dry synthetic mesh filter media.
- SynthaMax dry flowing synthetic layer.
- Washable and reusable.
- Short flange design with a 4 in. flange.
- 6 in. base and 9 in. length.
Clearance and airflow
A longer filter body is more sensitive to clearance than a compact one. Before installing, look at the space above, below and beside the housing for hoses, brackets and wiring. A body that presses against nearby parts can rub, wear or loosen connections over time.
Flange and base dimensions determine how the filter seats, and a short flange needs to sit flat against the housing opening. Check that the flange is free of debris and that the clamp or fasteners pull it evenly, so the seal holds along the whole edge.
Dry synthetic mesh is cleaned and reused rather than oiled. Dust gathers on the outer layers first, so light tapping and rinsing usually restore airflow. Look for distortion in the body after washing, since a bent body can change the seal.
- Measure clearance before installing
- Seat the short flange flat
- Tap out dust before rinsing
- Check the body for distortion
Specifications
| Brand | AIRAID |
|---|---|
| Part number | 701-471 |
| UPC | 642046744717 |
| Filter type | Dry |
| Washable | Yes |
| Filter material | Synthetic mesh |
| Replacement type | OEM replacement |
| Flange | 4 in. |
| Base | 6 in. |
| Height | 4-5/8 |
| Length | 9 in. |
| Flange style | Short flange |
| Warranty | Lifetime No-Hassle warranty. |
| Made in | U.S.A. |
Vehicle fitment
Confirm the 9 in. length has room in the housing before installing. A longer body needs more clearance than a compact filter.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Confirm the 9 in. length has room in the housing before installing, since the longer body needs more clearance than shorter filters in this line.
