Spidertrax Offroad Wheel Spacers (Anodized Blue) – WHS002

Spidertrax Offroad

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Bolt pattern 5 on 4.5 with 1.25 inch thick spacers
  • 6061T6 aluminum, anodized dark blue
  • Kit includes 2 spacers, 10 pre-installed wheel studs, 10 lug nuts and Loctite
  • Named for Jeep XJ, YJ, TJ, ZJ, KJ and KK axles; check fitment before ordering

Description

Overview

The Spidertrax Offroad WHS002 wheel spacers are 1.25 inch thick aluminum spacers for a 5 on 4.5 bolt pattern, finished in anodized blue. Spidertrax describes them as a way to space front and rear axles on Jeep XJ, YJ, TJ, ZJ, KJ and KK models.

Each spacer is made of 6061T6 aluminum and double anodized in dark blue, which gives it corrosion resistance. The spacers are wheel and hub centric and made in the USA.

Key features

  • 1.25 inch thickness with a 5 on 4.5 bolt pattern
  • 6061T6 aluminum body
  • Double anodized dark blue finish
  • Wheel and hub centric design.
  • Kit includes 2 spacers, 10 pre-installed wheel studs, 10 lug nuts and Loctite
  • Made in the USA

Hub-centric fit and studs

Hub spacers sit between the hub and the wheel, so the wheel is pushed outward while the studs and nuts carry the same clamping load. Thickness changes the leverage on the wheel bearings and the outer axle. Anodized aluminum resists corrosion well, but the hub face still needs cleaning before each mount.

Pre-installed studs help keep the install simple, but each stud should still be checked for thread engagement through the spacer and into the nut. Loctite is included, and it is used on the threads to help keep nuts in place. Clean the threads before applying it, and follow the torque your vehicle requires.

Spacers also change tire clearance, so recheck the fenders, steering stops and brake parts after the first drive. Torque the nuts again once the spacers have settled, and inspect the studs for bending or movement. A wheel that wobbles or clicks after fitting needs immediate attention.

  • Check stud thread engagement
  • Clean hub face and threads
  • Recheck torque after the first drive

Specifications

Brand Spidertrax Offroad
Part number WHS002
UPC 8403674937
Bolt pattern 5 on 4.5
Thickness 1.25 inch
Material 6061T6 aluminum
Finish Anodized blue, dark blue double anodized
Spacers per kit 2
Wheel studs 10 standard, pre-installed
Lug nuts 10
Thread locker Loctite
Origin Made in the USA

Vehicle fitment

Spidertrax names front and rear Jeep XJ, YJ, TJ, ZJ, KJ and KK axles, but no structured fitment list is published and no model years are given. Confirm your vehicle’s year, model and trim before ordering.

Applications cover only those chassis codes. Jeep JK, JL and other models are not part of this fitment.

Installation notes

The 10 wheel studs come pre-installed and Loctite is included. Hub-mounted spacers change clearance, so recheck tire and steering clearance after fitting.

What’s included

Two wheel spacers, 10 standard wheel studs (pre-installed), 10 lug nuts and Loctite.

SKU: SPIWHS002 Category:

Specification

Shipping weight 6.05 lbs
Package dimensions 7.10 × 7.10 × 4.50 in
brands

Questions & Answers

What bolt pattern do the Spidertrax WHS002 spacers use?

The WHS002 uses a 5 on 4.5 bolt pattern. The spacers are 1.25 inch thick, made of 6061T6 aluminum, and finished in anodized blue.

Do the WHS002 spacers fit a Jeep XJ, YJ or TJ?

Spidertrax names front and rear axles on Jeep XJ, YJ, TJ, ZJ, KJ and KK models, but no model years are given. Confirm your vehicle's year, model and trim before ordering.

What is included with each WHS002 kit?

Each kit includes 2 wheel spacers, 10 standard wheel studs that come pre-installed, 10 lug nuts and Loctite. The spacers are made in the USA.

Are these spacers corrosion resistant?

Yes. Spidertrax double anodizes the spacers in dark blue, which it says gives twice the corrosion resistance. No warranty term is given, so check the brand's coverage details.

Do thicker spacers need a different wheel stud?

Often, yes. A spacer moves the wheel farther out, so the studs must reach through the spacer with enough thread for the nut to seat fully. Check thread engagement before driving, and confirm the stud length suits the spacer thickness.

How should spacer bolts be maintained?

Check the nuts after the first short drive and again after longer trips. Keep threads clean and lightly coated only where the instructions allow, and inspect the studs for stretching or thread wear at each tire rotation.
