Overview
The Rubicon Express RE1860-165 is a CVO drive shaft that is 16.5 inches long. It is compatible with 1310 yokes and is intended for the rear position, with a slip yoke eliminator required.
Lengths are measured center to center on the U-joint, with the slip stub at the center of its travel. Measure the vehicle on the ground in its running position before choosing the length.
Key features
- 16.5-inch length
- Compatible with 1310 yokes
- Rear position
- Slip yoke eliminator required
- Measured center to center on the U-joint
Driveline length and measurement
A driveshaft has to be the correct length to keep the U-joint angles within range through the full suspension cycle. Too long a shaft can bottom out the slip joint, while too short a shaft can pull apart when the axle drops. Taking the measurement at ride height on level ground gives a reliable baseline before any ordering or installation.
When the slip yoke is removed, the transfer case output sits in a different position, so the eliminator and the shaft work together as one system. Inspect the yoke seals and the eliminator bolts after installation. Check for vibration at highway speed, since a mismatched length or angle often shows up there first.
- Measure with the tires at their normal ride height
- Compare the yoke size before buying a shaft or eliminator
- Recheck driveline angles after changing lift or axle position
Specifications
| Brand | Rubicon Express |
|---|---|
| Part number | RE1860-165 |
| UPC | 614901439052 |
| Length | 16.5 inches |
| Yoke | 1310 |
| Type | CV |
| Position | Rear |
| Slip yoke eliminator | Required |
Vehicle fitment
Confirm the yoke size and measure your vehicle in its running position before ordering.
Installation notes
The slip yoke eliminator is required with this shaft. Measure the length in the running position, since center to center length depends on where the slip stub sits in its travel.
What’s included
One 16.5-inch CVO drive shaft.
Not included: the slip yoke eliminator, which is required for this shaft.
