Rubicon Express 5.5 Plus Inch Spring-Over Conversion Lift Kit – No Shocks – RE5015

Rubicon Express

Shop Jeep Wrangler YJ Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • 5.5-inch net-lift spring-over conversion that keeps stock-height springs
  • Spring perches, spring plates, brake lines and a drop pitman arm included
  • Shocks not included
  • Steering modifications are needed on a spring-over conversion
  • Fits the 1987-1995 Jeep Wrangler (YJ)

Description

Overview

The Rubicon Express RE5015 is a spring-over axle conversion lift kit that moves the leaf spring perches to the top of the axle. With stock-height springs it gives a net lift increase of at least 5.5 inches, which keeps the factory ride quality. It is offered without shocks and fits the 1987-1995 Jeep Wrangler (YJ).

Installing the kit means removing the original spring perches and welding new perches in place, along with other adjustments. A CV-type drive shaft is recommended for this application, and steering modifications are needed on a spring-over conversion. The RE1445 and RE1444 Extreme-Duty leaf springs are the recommended pairing for greater durability and a total of 7 inches of lift.

Key features

  • 5.5-inch minimum net lift with stock-height springs
  • Spring-over conversion that moves the leaf spring perches to the top of the axle
  • Spring perches and spring plates included
  • Brake lines and drop pitman arm included
  • Instructions and hardware included
  • Option to use RE1445 and RE1444 leaf springs for 7 inches of lift

Spring-over axle planning

A spring-over conversion changes how the axle sits under the frame, so the work goes beyond the spring pack itself. The leaf springs, perches and shackle geometry all move, which affects pinion angle and the way the axle tracks under load. Plan for a driveline check after the swap, and recheck the U-bolts once the vehicle has been driven a short distance.

Steering geometry needs attention too, since the drop pitman arm and related linkage work change steering angles. Many owners also inspect the brake hoses after the conversion, because the axle position shifts. Good welds on the new perches matter more than almost anything else, so use a fabricator who knows axle work and inspect the welds periodically for cracks.

  • Check U-bolt torque after the first drives
  • Inspect brake hoses for stretch or chafing
  • Recheck steering alignment after the swap

Specifications

Brand Rubicon Express
Part number RE5015
UPC 614901441390
Kit type Spring-over axle conversion
Lift height 5.5 inches minimum net (chart range 5 to 6.99 inches)
Included parts Spring perches, spring plates, brake lines, drop pitman arm
Rear lift method Stock leaf spring
Shocks Not included

Vehicle fitment

It fits the 1987-1995 Jeep Wrangler (YJ) across several trim names.

The TJ, JK and JL generations are not part of this list. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

This conversion requires removing the original spring perches and welding new perches in place, along with other adjustments. Steering modifications are needed, and a CV-type drive shaft is recommended for this application.

What’s included

The kit includes spring perches, spring plates, brake lines, a drop pitman arm, instructions and hardware.

Not included: shock absorbers.

Spring-over conversions move the leaf spring perches to the top of the axle, and with stock-height springs they keep the factory ride quality. Steering modifications and a CV-type drive shaft are part of planning for this conversion.

SKU: R/ERE5015 Category:

Specification

Shipping weight 25.00 lbs
Package dimensions 15.00 × 9.00 × 6.00 in
brands

Fitment

VehicleYearsTrims
Jeep Wrangler (YJ)1987–1995Base, Islander, Laredo, Renegade, Rio Grande, S, SE, Sahara, Sport

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the RE5015 include shocks?

No. The fitment details list shocks as not included, so existing shocks or a separate set will be needed. The fitment details list shocks as not included, so a separate set is needed.

Is welding required?

Yes. The installation removes the original spring perches and welds new perches in place. The stock-spec springs keep the factory ride quality.

How much lift does the RE5015 give?

It gives a net lift of at least 5.5 inches with stock-height springs. RE1445 and RE1444 leaf springs are the recommended pairing for a total of 7 inches. It fits the 1987-1995 Jeep Wrangler (YJ).

Which Jeeps does the RE5015 fit?

The listed fitment is the 1987-1995 Jeep Wrangler (YJ). Confirm your vehicle's year, model and trim before ordering. The recommended leaf springs are the RE1445 and RE1444 Extreme-Duty pair.

Is a spring-over conversion suitable for daily driving?

It can be, when the work is done carefully. Expect a firmer or different feel than stock, and plan for steering and driveline checks. Keep up regular inspection of the perches and welds, since they carry the axle load.
