Overview
The Rubicon Express RE7514 is a 4.5-inch Extreme-Duty long arm lift kit with a rear Tri-Link, made for the 2003–2006 Jeep Wrangler TJ. It is sold without shocks, and the lift range is 3 to 4.99 inches.
This kit is a complete suspension replacement. The longer control arms improve lifted geometry and give more stability on and off road, with reduced torque roll and better trail traction than a standard short arm lift.
The rear Tri-Link takes the place of the rear track bar. It lets the axle travel up and down in a straight line, adds anti-squat for steep climbs and improves road tracking.
Key features
- Chromoly long arms built from 4130 chromoly tubing
- Rear Tri-Link that replaces the rear track bar
- Builder Ball misalignment joint, rated by Rubicon Express for up to 32 degrees
- Adjustable control arms with serviceable Super-Flex spherical ball joints
- PT-Meg Super-Ride bushings
- Tuned lift springs and stainless steel brake lines
- Three-piece belly pan for transfer case and transmission access
Sizing a long arm kit
Choosing a long arm kit starts with the lift height you need and the tires you plan to run. A 4.5-inch system leaves room for moderate tire growth, but tire diameter, fender trim and bump travel all shape how the vehicle performs. Keep the expected load in mind too, since a heavier build puts more strain on the new arms and joints.
Because this kit ships without shocks, budget for a shock set that matches the new arm position and lift height. Many owners also replace bump stops, brake hoses and worn bushings at the same time. Inspect the Builder Ball boot and Tri-Link bolts after the first few trail runs, and check driveline angles again after any change in tire size.
- Match shock length to the new arm position
- Check brake hose length at full articulation
- Re-torque Tri-Link bolts after the first trail runs
Specifications
| Brand | Rubicon Express |
|---|---|
| Part number | RE7514 |
| UPC | 614901442052 |
| Lift height range | 3 to 4.99 inches |
| Suspension type | Long arm |
| Kit type | Extreme-Duty long arm |
| Rear lift method | 3-link (Tri-Link) |
| Control arm material | 4130 chromoly, .250 wall |
| Misalignment joint | Builder Ball, up to 32 degrees, 3 inch OD housing |
| Belly pan | Three-piece, for transfer case and transmission access |
| Shocks included | No |
| Fitment | Direct fit |
Vehicle fitment
It fits the 2003–2006 Jeep Wrangler (TJ), including the 65th Anniversary Edition, Rubicon, SE, Sahara and Sport models.
Confirm your vehicle’s year, model and trim before ordering, including whether it is a 1997–2002 TJ, JK or YJ.
Installation notes
The long arms change alignment and driveline angles, so both should be checked once the kit is installed. It is bolt-on for factory Dana 35 and Dana 44 rear axles.
What’s included
The kit includes front and rear control arms, the rear Tri-Link, the Builder Ball, PT-Meg Super-Ride bushings, tuned lift springs, stainless steel brake lines and a three-piece belly pan.
Not included: shocks.
