Overview
The Rancho RS77068 is a rear RS7MT monotube shock for the 2018 through 2026 Jeep Wrangler (JL) with a 3.5-inch or 4.5-inch lift. It also fits the 2020 through 2026 Jeep Gladiator.
This is the longest rear unit in the RS7MT range, with a compressed length of 19.76 inches, an extended length of 31.18 inches and 11.42 inches of travel. Both ends use eyelet mounts.
The RS7MT is built for the pavement and the trail, with valving tuned to the application for on-road and off-road handling. The internal rebound bumper and shouldered rubber bushings reduce noise, vibration and ride harshness.
The body withstands internal temperatures of -40 to 248 degrees Fahrenheit, and the 14 mm hardened chrome piston rod resists scuffs and corrosion. The finish is black satin with a red Rancho logo.
Key features
- Rear monotube shock for the Wrangler JL with a 3.5 or 4.5-inch lift
- Internal rebound bumper and shouldered rubber bushings
- PTFE-banded piston that Rancho says improves responsiveness
- Deflective disc valving with digressive, linear or progressive turning
- Application-specific mounting with no sleeves or extra hardware
- High-pressure nitrogen gas and full-floating dividing piston
Clearance on a long-travel rear
A long rear shock needs room at both ends of its stroke. At full extension it can reach the mount area and the frame or crossmember, and at full compression it needs space around the body. Before installing, check that the lower eyelet and the upper bracket have clean sides and that nothing rubs when the axle cycles.
Fitting a longer shock also changes how the rear suspension behaves at the limits of travel. Bump stops and the brake line routing should be checked after the first drive, since a larger stroke can reach areas that the old shock never did.
- Check the shock at full extension and full compression
- Inspect brake lines and wiring near the upper mount
- Confirm bump stops still clear the body
- Retighten all eyelet bolts after the first drive
Specifications
| Brand | Rancho |
|---|---|
| Part number | RANRS77068 |
| Series | RS7MT |
| Position | Rear |
| Shock type | Monotube |
| Compressed length | 19.76 inches |
| Extended length | 31.18 inches |
| Travel | 11.42 inches |
| Body diameter | 2.0 inches |
| Top and bottom mount | Eyelet |
Vehicle fitment
It is a rear shock for the 2018 through 2026 Jeep Wrangler (JL), in two-door and Unlimited four-door body styles, and for the 2020 through 2026 Jeep Gladiator.
The list does not include the Wrangler JK or Wrangler JL years before 2018. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
It is made for a 3.5 or 4.5-inch lift. With an extended length of 31.18 inches, check that the mounts and the space behind the axle clear the new unit before installing it.
What’s included
Check the package contents against your installation before starting.
