Pro Comp 64 Series Gunner, 20x10 with 5x150 Bolt Pattern – Satin Black Milled- 5164-215547

Pro Comp Alloy Wheels

Shop Pro Comp Alloy Wheels 20x10 on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • 20×10 aluminum eight-spoke wheel in satin black milled finish
  • 5 on 150 bolt pattern, -18 offset, 110 center bore
  • 3650-pound rating and CNC-milled windows
  • Two-year finish warranty and the Pro Comp Promise
  • Part number PXA5164-215547

Description

Overview

The Pro Comp 64 Series Gunner 20×10 is an aluminum eight-spoke wheel in satin black milled finish, with a 5 on 150 bolt pattern and a -18 offset. It measures 20 inches in diameter and 10 inches wide, with a 110 center bore and a 4.75 backspacing. Backspacing is the distance from the mounting face to the back edge of the wheel, so together with the -18 offset it shows how far the wheel barrel sits behind the hub.

The Gunner is part of the performance wheel line, with a chiseled eight-spoke design and CNC-milled windows. The satin black milled finish is the main visual feature, and the wheel is rated at 3650 pounds.

The Gunner carries a two-year finish warranty and the Pro Comp Promise, a fully transferable lifetime structural warranty. It is also offered in 17- and 20-inch diameters with 5-, 6- and 8-lug bolt patterns.

Key features

  • Eight-spoke design with CNC-milled windows
  • Satin black milled finish
  • 20-inch diameter and 10-inch width
  • 5 on 150 bolt pattern
  • -18 offset and 4.75 backspacing
  • 3650-pound rating
  • Aluminum construction

Choosing wheel offset and backspacing

Offset and backspacing determine how far the wheel sits in the wheel well and how much room it has for the brakes, suspension and fenders. A negative offset pushes the mounting face outward, so the tire sits farther out from the hub. That change can improve clearance for the brake caliper but may require more room at the fender. Measuring the existing clearance before buying a wheel helps avoid rubbing once the tire is mounted.

Bolt pattern and center bore must match the hub, while offset and backspacing decide how the wheel sits on it. Tire size, load rating and sidewall height also affect the final fit. Milled surfaces and satin black finishes are best kept clean with regular washing, since road grime can build up in the milled windows and dull the look over time.

  • Match the bolt pattern and center bore to the hub
  • Check brake caliper clearance behind the spokes
  • Confirm tire size clears the fenders at full travel
  • Use lug nuts that suit the wheel seat

Specifications

Brand Pro Comp Alloy Wheels
Part number PXA5164-215547
Series 64 Series Gunner
Series finish Satin black milled
Style Eight-spoke
Diameter 20 inches
Width 10 inches
Offset -18
Backspacing 4.75
Bolt pattern 5 on 150
Center bore 110
Construction Aluminum
Rating 3650 pounds
Warranty Two-year finish warranty; Pro Comp Promise lifetime structural warranty

Vehicle fitment

Pro Comp labels this wheel universal fit, but a wheel is only correct for a vehicle whose hub matches its bolt pattern, center bore and offset. Compare the 5 on 150 bolt pattern and the 110 center bore with your hub, and check tire and brake clearance for the -18 offset.

Confirm your vehicle’s year, model and trim before ordering.

What’s included

Not included: a tire, which must be added to complete the wheel.

SKU: PXA5164-215547 Categories: ,

Questions & Answers

What bolt pattern does the 64 Series Gunner 20x10 use?

It uses a 5 on 150 bolt pattern. The wheel is 20 inches in diameter and 10 inches wide, with a 110 center bore that centers it on the hub.

Does the Gunner come in other sizes?

Yes. The Gunner is available in 17- and 20-inch diameters, with 5-, 6- and 8-lug bolt patterns. Match the diameter and bolt pattern to your hub before ordering.

What warranty applies to the Gunner?

The wheel has a two-year finish warranty and the Pro Comp Promise, which is a fully transferable lifetime structural warranty. Keep proof of purchase with the wheel in case a warranty claim comes up.

What does the -18 offset do?

Offset is the distance from the wheel's mounting face to its centerline. A negative offset such as -18 moves the mounting face outward, so the wheel sits farther out than a zero or positive offset wheel of the same width.

How should a satin black milled finish be cleaned?

Wash with mild soap, water and a soft brush or sponge, then rinse fully. Avoid harsh acid-based cleaners and abrasive pads, which can dull the finish. Dry the wheel to prevent water spots in the milled surfaces.

Do wheels need checking after installation?

Yes. Recheck lug nut torque after the first drive and at regular intervals. Inspect the wheel for rubbing on fenders or suspension parts once the tire is mounted.
