Overview
Part number EXPK1009T (kit K1009T) is a 2.5-inch stage 1 suspension lift for 1973 to 1978 Chevrolet and GMC full-size trucks and Blazers. It covers the Chevrolet K10 and K5 Blazer, the GMC Jimmy and K15, and the K15 Suburban, across several trim packages.
The lift is 2.5 inches at stage 1, with a lift height range of 0 to 3.5 inches. The rear uses leaf springs, lifted with a block and U-bolt assembly. ES3000 shocks are fitted at the front and rear and are included with the kit.
Key features
- 2.5-inch stage 1 suspension lift
- Leaf spring rear lift with a block and U-bolt assembly
- ES3000 front and rear shocks included
- Lift height range of 0 to 3.5 inches
- Sized for 33-inch tires.
Leaf springs and U-bolts
Leaf springs on 1970s trucks control the rear axle through the leaf pack and shackles, so the block and U-bolt assembly needs to hold the axle firmly after the lift. Loose U-bolts are a common cause of axle shift, and they should be re-torqued after the first drives. Inspect the leaf pack for cracked or broken leaves before adding a lift.
A rear block changes the position of the axle relative to the frame, which affects pinion angle and driveline vibration. Measure the pinion angle after installation and check the driveshaft for play. Shackle bushings and spring eyes wear with age, and they can make the rear feel loose once the truck is raised.
- U-bolt torque and retightening
- Leaf pack condition
- Pinion angle measurement
- Shackle bushing wear
Specifications
| Brand | Pro Comp Suspension |
|---|---|
| Part number | EXPK1009T |
| Kit code | K1009T |
| Suspension type | Lift kit, stage 1 |
| Lift height | 2.5 inches stage 1; range 0 to 3.5 inches |
| Rear lift method | Leaf springs |
| Rear lift component | Block and U-bolt |
| Tire size | 33 inches |
| Front shocks | ES3000 |
| Rear shocks | ES3000 |
| Fit type | Direct fit |
Vehicle fitment
Covers 1973 to 1976 Chevrolet K10 and K5 Blazer, 1973 to 1974 Chevrolet Blazer, 1973 to 1976 Chevrolet K10 Suburban, 1973 to 1976 GMC Jimmy, 1975 to 1976 GMC K15, 1975 to 1978 GMC K15 Suburban and 1973 to 1974 GMC K15/K1500 trucks, including Base, Custom Deluxe, Scottsdale, Silverado, Sierra Classic and High Sierra versions.
The list does not include 1979 and later trucks. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The rear lift uses blocks and U-bolts on the leaf springs, so the rear height changes with the kit. Check the front and rear heights after installation, and have the alignment checked.
What’s included
The 2.5-inch stage 1 lift kit with ES3000 front and rear shocks.
