Overview
The Mag-Hytec F-A1000 is a transmission part for GM Allison A1000 applications, identified by part number F-A1000. It has heavy duty covers and pans cast from A356-T6 aluminum, built to add lubricant and cooling capacity for hard working recreational and service vehicles.
Key features
- Cast A356-T6 aluminum body with a texture powder coated black finish
- Machined cooling fins to increase cooling capacity
- Magnetic drain plugs trap worn gear material
- ARP 568 O-rings for sealing
- 303 stainless steel hardware
Fluid level and cooling
Automatic transmission covers and pans do two jobs: they seal the fluid in and they shed heat from the gear train. Extra fin area helps cooling in towing and heavy service, and a magnetic drain plug collects fine metal that would otherwise circulate. Aluminum conducts heat well, which suits a case that works hard.
A pan swap is a good time to inspect the magnets and filter, and to note any shavings. Clean the sealing surface before fitting the cover, and fill to the correct level once the transmission reaches operating temperature. Keep the drain plugs accessible for future fluid changes.
- Clean the sealing surface before fitting
- Check magnets at every fluid change
- Fill to the level for operating temperature
Specifications
| Brand | Mag-Hytec |
|---|---|
| Part number | F-A1000 |
| Application | GM Allison A1000; Duramax 2001 to 2010 |
| Body material | A356-T6 aluminum |
| Finish | Texture powder coated black |
| Seals | ARP 568 O-rings |
| Hardware | 303 stainless steel |
| Drain plugs | Magnetic |
| Warranty | Lifetime limited warranty |
Vehicle fitment
It fits all Duramax 2001 to 2010 applications. Duramax is an engine name rather than a vehicle model, so no specific truck model is identified.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Mag-Hytec says most applications need no gasket or sealant, since the ARP 568 O-rings provide the seal. Check your application before installing, and keep the magnetic drain plugs in place to catch worn gear material.
What’s included
The package includes 303 stainless steel hardware and ARP 568 O-rings. Check the package contents against your installation before starting.
