Overview
The Gorilla Automotive K5ES-14150BGR is a 20-piece set of black spline lug nuts with a 14mm x 1.5 thread. It is Universal Fit, so no make, model or year is tied to it.
Spline lug nuts are made for wheels with a matching spline seat, so the seat style and the 14mm x 1.5 stud size should be checked against your wheels before any of these nuts are installed. The black finish is the only color listed.
Key features
- Spline seat style for wheels with a spline bore
- Black finish
- 14mm x 1.5 thread size
- Kit count of 20 lug nuts
- Universal fit listing with no vehicle named
Spline seats and lug torque
Spline seats use a splined collar that fits a matching bore in the wheel, while conical and ball seats bear on a tapered or round surface. Mixing seat types on one wheel can leave some nuts loose, so the seat style should be identified before any nut is installed. Overtightening can stretch a stud, so use a torque wrench set to the value for your vehicle.
Spline nuts wear through repeated removal, particularly when threads are dirty or the collar has been struck with a tool. Replacing the nuts as a full set keeps the seating force even across the wheel. Clean the threads and inspect the studs when the wheel is removed, since damaged threads can make a correct nut feel tight without seating properly.
- Check the spline collar for rounding or cracks
- Clean threads before reinstalling
- Torque to the value for your vehicle
- Replace nuts that spin freely on the stud
- Avoid mixing seat styles on one wheel
Specifications
| Brand | Gorilla Automotive |
|---|---|
| Part number | GORK5ES-14150BGR |
| Style | Spline |
| Color | Black |
| Size | 14mm x 1.5 |
| Count | 20 |
| Fitment | Universal Fit |
Vehicle fitment
No vehicle is tied to this kit, which is Universal Fit. Thread size and seat type decide whether a lug nut seats properly, so match the 14mm x 1.5 thread and spline seat to your wheels and studs before buying.
Universal fit does not mean every wheel uses this seat or thread. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Use these nuts only on wheels whose seat is a spline bore; wheels with conical or ball seats need a different nut. Check each wheel’s seat type before fitting the set.
What’s included
The kit contains 20 black spline lug nuts in 14mm x 1.5 thread size.
