G2 Double Cardan CV Style Rear Drive Shaft – 92-2052-8

G2 Axle and Gear

Shop Jeep Wrangler JK Drive Shafts on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Rear Double Cardan CV drive shaft for four-door Jeep Wrangler JK models
  • Part number 92-2052-8, 1350 U-joint
  • Rated for stock to 6 inch lift and tires up to 37 inches
  • Heavy duty D.O.M. tubing, dynamically balanced

Description

Overview

Part number 92-2052-8 identifies this Double Cardan CV rear drive shaft from G2 Axle and Gear, made for four-door Jeep Wrangler JK models with an automatic transmission.

G2 Axle and Gear describes heavy duty replacement construction with D.O.M. tubing and solid body U-joints. Balancing is dynamic and intended to eliminate vibration, and the stated fit is stock to 6 inch lift with tires up to 37 inches.

Key features

  • Heavy duty D.O.M. tubing
  • Solid body U-joints
  • Dynamically balanced to eliminate vibration
  • Double Cardan CV driveshaft type
  • Rated for stock to 6 inch lift
  • Rated for tires up to 37 inches

Driveline angles after a lift

A rear driveshaft works with the pinion angle and the transfer case output angle, and a lift changes both. Once suspension height moves, joint angles can grow beyond what a CV-style shaft is designed to accept, which causes vibration at speed. Measure the angles with an inclinometer before and after any height change.

Tire size also matters, since larger tires change the gearing and add load on the driveline. Upgraded control arms or a pinion adjustment often accompany a lift, and those parts affect driveline geometry. Inspect the U-joint caps and the slip yoke for wear during any suspension work.

  • Check pinion angle with an inclinometer
  • Inspect U-joint caps for play
  • Look for vibration at highway speed
  • Re-torque yoke bolts after the first drive

Specifications

Brand G2 Axle and Gear
Part number 92-2052-8
UPC 631410130621
Position Rear
Driveshaft type Double Cardan CV
U-joint 1350
Tubing Heavy duty D.O.M.
Maximum lift height 6 inches
Tire size Up to 37 inches
Body style 4-door
Transmission Automatic

Vehicle fitment

This rear shaft is for the Jeep Wrangler JK (2007-2018), four-door models with an automatic transmission.

Two-door JK vehicles need one of the two-door rear shafts in this line, 92-2052-3 or 92-2052-7. Other Wrangler generations are not covered. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

This rear CV shaft does not need a slip yoke eliminator. Check driveline angles after any lift, since the rating ends at 6 inches.

What’s included

One rear Double Cardan CV drive shaft assembly.

SKU: G/292-2052-8 Category:

Specification

Shipping weight 35.00 lbs
Package dimensions 48.00 × 10.00 × 10.00 in
brands

Fitment

VehicleYearsTrims
Jeep Wrangler (JK) likely fits2007–2018All

Vehicles marked "likely fits" are inferred from the product description rather than a manufacturer fitment list. Please confirm fitment with the manufacturer before ordering.

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Is the 92-2052-8 made for four-door Wrangler JK models?

Yes. It is a rear drive shaft for four-door models with an automatic transmission. The two-door rear shafts in this line are 92-2052-3 and 92-2052-7.

What lift height is the 92-2052-8 rated for?

Stock to 6 inch lift, with a 6 inch maximum lift height listed. Tires up to 37 inches are rated for it. Check these numbers against your current build before installing.

Does this shaft require a slip yoke eliminator?

No. This rear CV shaft does not require a slip yoke eliminator. Its U-joint is a 1350, so check driveline angles after any lift to confirm the setup.

How often should a driveshaft be inspected?

Check it at every oil change or tire rotation. Look for grease leaks at the joints, play when you rock the shaft by hand, and vibration that changes with speed. Address wear early, since a failed joint can damage the transfer case or differential.
