Overview
The Dana Spicer Dana 44 crush sleeve, part number D/S43916, is an aluminum rear axle sleeve that sets pinion bearing preload on late model factory-style ring and pinions. Dana Spicer offers it as a replacement for dealer crush sleeves that are often hard to find.
It is built for late model axles that use factory crush sleeves, so it suits Grand Cherokee and Commander applications.
Key features
- Aluminum Dana 44 rear crush sleeve
- Maintains proper pinion bearing preload
- Designed for late model factory-style ring and pinions
- Direct replacement for dealer crush sleeves
Pinion preload and reassembly
Pinion preload is the rotational resistance of the pinion bearings, and it is set by tightening the nut until the sleeve reaches the right point. Too little preload lets the pinion move under load and wears the gears. Too much preload overheats the bearings and can damage the seal. Setting preload is a measured job, not a guess.
Solid spacers and crush sleeves are not interchangeable, so match the type the axle was built with. Measure the bearing turning torque as the nut is tightened and compare it against the axle’s setup procedure. Keep pinion depth and carrier bearing preload in mind, because a change in one can affect the others.
- Use a torque wrench on the pinion nut
- Check bearing rotating torque at each step
- Replace the pinion seal when the yoke is removed
Specifications
| Brand | Dana Spicer |
|---|---|
| Part number | D/S43916 |
| Axle type | Dana 44 |
| Position | Rear |
| Material | Aluminum |
| Ring and pinion | Late model factory style |
Vehicle fitment
It fits the 2006–2008 Jeep Commander (XK), the 1999–2004 Jeep Grand Cherokee (WJ), the 2005–2008 Jeep Grand Cherokee (WK) and the 1996–1998 Jeep Grand Cherokee (ZJ).
No Wrangler or Cherokee (XJ) models appear on the list, and the ZJ years are 1996 to 1998 only. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
A crush sleeve is compressed when the pinion nut is tightened to set bearing preload, so it is normally replaced whenever the pinion is set. Preload has to be set correctly, which is why a professional gear setup is usually recommended.
What’s included
The crush sleeve is the only part in the kit. Check the pinion nut and gear set against your installation before starting.
