Overview
The Dana Spicer 42102 is a crush sleeve for Dana 35 axles, made to replace the factory crush sleeve that sets pinion bearing preload. It is a direct replacement for dealer crush sleeves on late model axles that use factory crush sleeves, which can be hard to source and costly to buy.
Key features
- Direct replacement for factory style crush sleeves
- Designed for Dana 35 axles
- Made for late model axles equipped with factory crush sleeves
Crush sleeve versus solid spacer
Pinion bearing preload keeps the pinion gear steady under load, and it is set by tightening the pinion nut against the sleeve. A crush sleeve collapses to hold that setting, which means it is set once and replaced when the pinion is taken apart again. A solid spacer works differently and holds preload without crushing, so it is not a simple swap in every setup.
When replacing a crush sleeve, check the pinion bearings, pinion seal and carrier shims together. Old bearings that were already running loose can lose preload quickly and cause early wear. Use a torque wrench on the pinion nut, measure rotating torque, and recheck it after the first drives. A qualified shop can handle this with the right tools.
Specifications
| Brand | Dana Spicer |
|---|---|
| Part number | 42102 |
| UPC | 23913140939 |
| Axle type | Dana 35 |
| Axle location | Front or rear; confirm your housing before ordering |
| Fitment listed | Universal fit |
Vehicle fitment
The sleeve is made for Dana 35 axles. Check your axle housing before ordering.
Dana 35 is an axle model, not a vehicle. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
A crush sleeve collapses as the pinion nut is tightened to set bearing preload, so it is normally installed once during a pinion setup and replaced rather than reused. Have the pinion preload checked by a qualified shop.
What’s included
Only the crush sleeve is included.
Not included: Bearings and the pinion nut are not included with this sleeve.
