Dana 60 1350 Non CV Yoke Kit

Advance Adapters

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Advance Adapters 716292 Dana 60 1350 non CV yoke kit
  • Built to match a 1350 series U-joint
  • Designed for Dana 60 axles
  • UPC 808331029352

Description

Overview

The Advance Adapters 716292 is a Dana 60 1350 non CV yoke kit for the pinion end of a Dana 60 axle. The title points to a 1350 series joint and a non CV yoke style.

Advance Adapters makes four-wheel-drive and powertrain parts, including transfer case, transmission, overdrive and engine conversion components. This kit is one of its axle components, and the yoke is sized for the Dana 60 housing.

Key features

  • Non CV yoke style
  • Matches the 1350 series U-joint
  • Designed for Dana 60 axles
  • Advance Adapters part number 716292

Driveline angle and yoke fit

The pinion yoke is the link between the driveshaft and the axle gears. Getting the joint size and yoke style right matters, because a mismatch can bind, vibrate or wear the joint quickly. A non CV style works with a conventional U-joint, so the joint size must match the yoke.

Driveline angle has a big effect on vibration and joint life. After fitting, check that the pinion and transfer case angles are close, and adjust the driveshaft or lift as needed. Pinion bearing preload should also be set with the yoke in place, since the pinion nut controls it.

Replace the U-joint and seals while the yoke is off, since they are inexpensive to swap while the driveline is apart. Clean the yoke splines and check for grooves before refitting.

  • Measure the existing joint size
  • Check pinion seal condition
  • Inspect the yoke for grooves
  • Verify driveline angle after fitting

Specifications

Brand Advance Adapters
Part number 716292
UPC 808331029352
Axle type Dana 60
U-joint series 1350
Yoke style Non CV

Vehicle fitment

The yoke is sized for the Dana 60 housing and a 1350 series joint, so it is a housing-specific part rather than a universal one. Make sure the fit lines up with your vehicle’s year, model and trim before ordering.

Other axle types and U-joint series are outside this kit. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Check that your existing U-joint is a 1350 series before choosing this kit, because the yoke and joint must match. Set pinion bearing preload and check the driveline angle after fitting.

What’s included

Count the arriving parts against your install plan before fitting.

SKU: ADV716292 Category:

Specification

Shipping weight 3.00 lbs
Package dimensions 6.80 × 4.50 × 4.30 in
brands

Questions & Answers

What is the Advance Adapters 716292?

It is a Dana 60 1350 non CV yoke kit, part number 716292, from Advance Adapters. The UPC is 808331029352, and the yoke is sized for the Dana 60 housing with a 1350 series joint.

Will this kit fit my truck?

No vehicle years or models are named, so fitment cannot be confirmed for a specific truck. Confirm that your axle is a Dana 60 and that your U-joint is a 1350 series before fitting.

Is the U-joint included with the kit?

Check the package contents against your installation before fitting, including whether a U-joint, nut or seal is in the box. Plan to inspect the existing U-joint and seals at the same time.

How do I know if the yoke is worn?

Look for grooves, pitting or a loose fit on the yoke ears and splines. A worn yoke can cause clunking or vibration under load and may wear new joints quickly. Measure and inspect the yoke before fitting the kit.

Is this yoke compatible with a CV joint?

No. It is a non CV yoke, so it is intended for a conventional U-joint rather than a CV joint. Choose a CV yoke if your driveline uses CV joints.
