Overview
The Bilstein 4600 Series rear shock absorber, part number 24-021791, is a gas-charged monotube shock for the 1999–2000 Cadillac Escalade in Base trim, the 1995–2000 Chevrolet Tahoe in Base, LS, LT and Z71 trims, and the 1995–2000 GMC Yukon in Denali, SLE and SLT trims. It has a 2 in body diameter, a yellow finish and boots included.
Heat leaves the oil through the monotube body and moves into the outer shock tube, where it dissipates. The dividing piston lets the oil swell as it warms so foaming and thinning are limited, and the piston head tunes compression and rebound damping independently. The stated lift height is w/0 in. Lift/Drop.
Key features
- Monotube gas-charged shock with a heat path from the oil to the outer tube
- Dividing piston for oil expansion as heat builds, limiting aeration and viscosity loss
- Seamless monotube made by extrusion for tight peak-to-valley tolerance
- Piston head that lets compression and rebound damping be tuned separately
- Fewer parts than most twin tube and road sensing designs.
- Boots included with the unit
Rear shocks on GM trucks
On full-size GM trucks and SUVs the rear shocks control body motion when the load changes, from a trailer hitch to a full cargo bed. A gas-charged monotube design keeps the damping steady as the oil heats during long grades, and the separate piston head lets compression and rebound be tuned independently. These are the features that make a rear shock feel planted.
Rear shocks often wear out before the springs, and worn units can make a truck bounce after dips or sway on corners. Replace them in pairs for even control, and inspect the rubber bushings and mount hardware while the old shocks are off. Check the boots for cracks, since debris at the shaft shortens shock life. A bounce test helps: push down on each rear corner and see whether the body rebounds once.
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-021791 |
| UPC | 651860420684 |
| Series | 4600 Series |
| Position | Rear |
| Body diameter | 2 in |
| Type | Monotube |
| Hydraulic / gas charged | Gas charged |
| Reservoir | No |
| Boots included | Yes |
| Finish | Yellow |
| Lift height | w/0 in. Lift/Drop |
| Fitment type | Direct Fit |
Vehicle fitment
This rear shock fits the 1999–2000 Cadillac Escalade in Base trim, the 1995–2000 Chevrolet Tahoe in Base, LS, LT and Z71 trims, and the 1995–2000 GMC Yukon in Denali, SLE and SLT trims. Confirm your vehicle’s year, model and trim before ordering, since these are the only fitments covered.
Model years 2001 and later, and trims not shown here, are outside this fitment. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Confirm that the mounting points on your old rear shock match this unit before removing it, and have the needed hardware ready. Rear shocks affect ride and load control, so after installing, check that every fastener is secure and the boots are seated before driving.
What’s included
One rear shock absorber with boots included.
Not included: Mounting hardware and any other pieces; check your kit before starting.
