Overview
The Bilstein 24-185387 is a front 4600 Series gas-charged monotube shock absorber with a 2 in body diameter, listed by the manufacturer for the 2001–2007 Toyota Sequoia (Limited, SR5) and the 2000–2006 Toyota Tundra (Base, Limited, SR5). It is a direct-fit shock with a yellow finish, no external reservoir and boots included.
Monotube gas-charged body with a dividing piston that lets the oil expand as heat builds, which helps prevent foaming and keeps damping at full strength as temperatures rise. The tube is seamless, formed by extrusion, and carries heat from the oil to the outer shock body.
Key features
- Patented monotube gas-charged body that moves heat from the oil to the outer shock body
- Dividing piston lets the oil expand as heat builds, reducing aeration and viscosity loss
- Seamless extruded tube with tight peak-to-valley tolerance and consistent wall thickness
- Piston head allows independent tuning of compression and rebound damping forces
- Fewer parts than most conventional twin tube and road sensing designs.
- Boots included
Gas pressure and handling
Toyota Sequoia and Tundra trucks are heavy vehicles, so the front shocks control a lot of weight transfer under braking and cornering. A gas-charged monotube design resists foaming as the oil warms, which keeps damping more predictable on long downhill runs. The seamless tube and piston head allow the valving to be tuned for compression and rebound separately.
Gas-charged shocks carry a pressurized charge, so the body should never be cut, heated or punctured. Store the unit upright and out of direct sun until it is installed. A shop familiar with gas shocks can dispose of the old unit safely, and inspecting the mounts at the same time helps the new shock last.
- Keep the boot clean during installation
- Replace in pairs on the same axle
- Check mount bushings for wear
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-185387 |
| UPC | 790832510128 |
| Shock series | 4600 Series |
| Body diameter | 2 in |
| Type | Monotube |
| Hydraulic / gas charged | Gas charged |
| Position | Front |
| Fitment | Direct fit |
| Reservoir | No |
| Boots included | Yes |
| Finish | Yellow |
| Lift / drop | 0 in. (none) |
Vehicle fitment
It fits the 2001–2007 Toyota Sequoia in Limited and SR5 trims and the 2000–2006 Toyota Tundra in Base, Limited and SR5 trims. It is a direct-fit front shock.
Sequoia years outside 2001–2007 and Tundra years after 2006 are not in the list, and generations not named here are not covered. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
This front shock has 0 in. lift or drop, so it suits a stock-height suspension. Gas-charged shocks hold pressurized gas, so have a shop familiar with them handle removal and disposal.
What’s included
Boots are included with the shock absorber.
Not included: Confirm that mounting hardware is in the box or on hand before you start the install.
