  • Front bypass shock, part number BP5160022, for the Jeep Wrangler JK
  • Fits the 2007–2018 Jeep Wrangler (JK), including Unlimited versions
  • Designed for a 3-4 in. lift
  • Mount part number VM80010014 required for installation

Description

Overview

The ARB BP5160022 is a front Old Man Emu BP-51 bypass shock absorber from ARB 4×4 Accessories for the 2007–2018 Jeep Wrangler (JK), covering the Wrangler and Unlimited trim families. It is a direct fit, gas charged, and designed for a 3-4 in. lift.

The BP-51 range was developed by Old Man Emu, and ARB says its shocks combine a comfortable ride around town with significant end-zone damping for control off road. The remote reservoir and bypass valving are the core of the design, and the body is aluminum for durability.

The big bore body is designed to fit without any vehicle modification. It gives a comfortable ride around town and a more controlled feel over challenging terrain, using patent-pending bypass technology. Part number BP5160022 and UPC 9332018037084 identify the unit. The mount part VM80010014 is required for installation, so check it before ordering.

Bypass damping works alongside speed-sensitive damping. As the piston approaches full compression or extension, the damping rises, so the shock slows before the bump stop and takes large bumps and corrugations smoothly.

Key features

  • Bypass damping that depends on piston position
  • Remote reservoir design
  • Installs without any extra vehicle modification.
  • Aircraft-grade 6061 T6 aluminum body
  • Designed for a 3-4 in. lift

Choosing a lift-matched shock

Lift height changes the geometry of the front suspension, so a shock must be matched to the ride height it is designed for. A shock with a body length that does not suit the setup can run out of travel early or sit with too little extension at full droop. Matching the shock to the spring and lift is the first step before any tuning.

Bypass shocks with a remote reservoir handle heat better than many standard units, which matters on long climbs and descents. Because the reservoir needs space and a secure mount, check hose routing and clearance against the front crossmember and steering components before the vehicle is driven.

After installation, check that the shock moves freely through full travel and that the reservoir does not rub. Inspect the mounts and bushings at regular service intervals, and recheck fasteners after the first few trail runs. Oil seepage at the seals or a sudden change in ride quality usually means the shock needs attention.

  • Match the shock to the lift and spring setup
  • Check reservoir clearance and hose routing
  • Recheck fasteners after the first trail runs

Specifications

Brand ARB 4×4 Accessories
Part number BP5160022
UPC 9332018037084
Position Front
Lift height w/3-4 in. lift
Shock type Gas charged
Body material 6061 T6 aircraft-grade aluminum
Fitment type Direct fit

Vehicle fitment

It fits the 2007–2018 Jeep Wrangler (JK), covering the Sport, Sport S, Sahara, Rubicon and X versions and their Unlimited counterparts. Other Wrangler generations are not covered.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Mount part number VM80010014 is required for installation. Because the lift is 3 to 4 inches, check the spring and ride height on your Wrangler against that figure before fitting the shock.

What’s included

The mount part VM80010014 is required and sold separately. Check the package contents against your installation before starting.

SKU: ARBBP5160022 Category:

Specification

Shipping weight 13.00 lbs
Package dimensions 35.00 × 7.00 × 4.00 in
brands

Fitment

VehicleYearsTrims
Jeep Wrangler (JK)2007–201870th Anniversary, 75th Anniversary, Rubicon, Sahara, Sport, Sport S, Unlimited 70th Anniversary, Unlimited 75th Anniversary, Unlimited Rubicon, Unlimited Sahara, Unlimited Sport, Unlimited Sport S, Unlimited X, X

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Is the ARB BP5160022 a lift shock?

ARB lists its lift height as w/3-4 in. lift, so the entry is for a setup with that lift. It is a front bypass shock for the 2007–2018 Jeep Wrangler (JK).

Does the ARB BP5160022 fit a 2010 Jeep Wrangler Unlimited?

Yes. The 2007–2018 Jeep Wrangler (JK) range includes the Unlimited versions, so a 2010 Unlimited falls within it. Confirm the trim on your vehicle before ordering.

Which mount do I need for the BP5160022?

Mount part number VM80010014 is required for installation. It is not included with the shock, so order it with the BP5160022.

Should the front shocks be replaced when a Wrangler gets a lift?

Often yes, because a lift changes the travel the shock must cover. Replacing old front shocks with units designed for the new ride height helps keep the suspension working as intended, and worn units may not keep up with the new geometry.

How do I know if the bypass shock is leaking?

Look for oil on the shock body, around the reservoir hose and at the seals. Wetness that builds up over time suggests a seal problem, and a shock with lost damping often makes the front end feel bouncy or loose.
