Advance Adapters Dana 300 Rotation Kit for AX-15 – 50-8603

Advance Adapters

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Advance Adapters Dana 300 rotation kit for AX-15, part number 50-8603
  • Works on Jeep Dana 300 transfer cases with a 23 spline input
  • Adapter is .75-inch thick with a longer input shaft
  • Floorboard and shifter modification may be required

Description

Overview

The Advance Adapters Dana 300 rotation kit for AX-15, part number 50-8603, is an adapter kit that clocks a Dana 300 transfer case to a higher than stock rotation. It works on Jeep Dana 300 transfer cases with a 23 spline input.

Raising the rotation addresses ground clearance, which Advance Adapters notes is a concern for most vehicles. The kit allows up to four different rotations than stock and keeps the proper spline engagement and indexing for the Dana 300. The Dana 300 must be used with a passenger side front axle.

Key features

  • Adapter is .75-inch thick
  • Includes a new, longer input shaft for the Dana 300
  • Up to four different rotations than stock
  • Keeps proper spline engagement and indexing for the Dana 300
  • Works on Jeep Dana 300 transfer cases with a 23 spline input

Rotation and driveline geometry

Rotating a transfer case changes the angle and position of the output shafts, which in turn changes driveshaft angles and the relationship between the transfer case and the floor. An adapter that raises rotation can help with ground clearance or larger tires, but it also moves the driveline out of its original geometry. Driveshaft angles should be checked after installation, because vibration at speed is a common sign that they have drifted too far.

Before ordering, confirm the input spline, the axle position and how much room the shifter and floorboard have. Plan for floorboard and shifter work, and check that the new input shaft clears the transmission and crossmember. After installation, inspect the driveshafts, U-joints and seals for wear, and recheck the fasteners after the first few trail runs.

Specifications

Brand Advance Adapters
Part number 50-8603
UPC 808331005394
Transfer case Dana 300
Input spline 23 spline
Adapter thickness .75-inch
Rotation Up to four different rotations than stock
Front axle position Passenger side

Vehicle fitment

Confirm the year and model of your vehicle, along with the Dana 300 input spline and axle position, before ordering.

This kit does not work with a 27 or 32 spline input into a Dana 300.

Installation notes

Floorboard and shifter modification may be required. Confirm the input spline on your Dana 300 is 23 before ordering, because the kit works only with that input.

What’s included

The kit includes the .75-inch adapter and a new, longer input shaft for the Dana 300.

Not included: floorboard and shifter modifications, which may be required.

SKU: ADV50-8603 Category:

Specification

Shipping weight 15.00 lbs
Package dimensions 11.00 × 11.00 × 11.00 in
brands

Questions & Answers

Which vehicles does the Advance Adapters 50-8603 fit?

It works on Jeep Dana 300 transfer cases with a 23 spline input, used with a passenger side front axle. Confirm the input spline and axle position on your vehicle before ordering.

Will the 50-8603 work with a 27 or 32 spline input?

No. It does not work with adapter kits that use a 27 or 32 spline input into a Dana 300. Only the 23 spline input is compatible.

Does this kit require floorboard or shifter changes?

Yes, floorboard and shifter modifications may be required. The kit includes the .75-inch adapter and a new, longer input shaft.

How do I know if the rotation kit has changed my driveline angles?

Vibration that rises with speed, or U-joints that bind or wear quickly, points to altered angles. Measure the angles with an inclinometer before and after installation, and correct them with the appropriate driveshaft or yoke work.
