Advance Adapters Atlas Speedometer Housing Assembly – 301506

Advance Adapters

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Speedometer pinion gear holder for 1982–1986 Jeep CJ vehicles
  • Works with Atlas and Dana 300 transfer cases
  • Billet aluminum, machined to factory OEM specifications
  • Replaces the discontinued OEM holder S-2538608
  • Part number 301506, UPC 70000423917

Description

Overview

The Advance Adapters 301506 is a billet aluminum speedometer housing assembly that holds the speedometer pinion gear. It is a replacement for the OEM pinion gear holder used on 1982–1986 Jeep CJ vehicles with an Atlas or Dana 300 transfer case. Advance Adapters identifies the original as OEM reference S-2538608.

The original holder has been discontinued and was previously available only as a salvage or reconditioned unit, which made it hard to find. This billet aluminum version is machined to factory OEM specifications for owners who need a replacement.

Key features

  • Billet aluminum speedometer pinion gear holder, machined to factory OEM specifications
  • Replaces the discontinued OEM holder, reference S-2538608
  • Made for the Atlas transfer case and the Dana 300 transfer case
  • Covers the 1982–1986 Jeep CJ speedometer setup

Speedometer drive calibration

The speedometer reads correctly only when the pinion holder and drive gear work together with the tire size and axle gear ratio. A tire that is larger or smaller than stock changes how many revolutions the speedometer cable sees per mile, so the reading drifts unless the gear is matched. Plan the tire and gear combination first, then choose the drive gear, and only then install the holder.

When replacing the holder, inspect the speedometer cable, the seal around the housing and the transfer case output area for wear or leaks. Clean old grease and debris from the housing bore before fitting the new unit. A bent or kinked speedometer cable can also cause erratic readings, so check it during the work. Record the gear size used so future replacements match the original setup.

  • Match drive gear to tire size and axle ratio
  • Inspect the speedometer cable for kinks
  • Clean the housing bore before fitting
  • Record the gear size used for future service

Specifications

Brand Advance Adapters
Part number 301506
UPC 70000423917
Part type Speedometer housing assembly (pinion gear holder)
Material Billet aluminum
Replaces OEM speedometer pinion gear holder S-2538608 (discontinued)
NSN 3040011923673
Transfer cases Atlas and Dana 300
Drive gear Sold separately, PN300620

Vehicle fitment

It fits 1982–1986 Jeep CJ vehicles that use an Atlas or Dana 300 transfer case. Confirm fit for your vehicle’s year, model and transfer case before ordering.

The speedometer assembly is not needed on 1987-and-newer Jeep vehicles.

Installation notes

The drive gear is sold separately as PN300620. The correct gear depends on the speedometer calibration for your tire size and axle gear ratio, so choose it along with this holder rather than after the holder is fitted.

What’s included

The box contains the billet aluminum speedometer pinion gear holder. The drive gear is not included and is sold separately as PN300620.

SKU: ADV301506 Category:

Specification

Shipping weight 2.00 lbs
Package dimensions 6.00 × 6.00 × 4.00 in
brands

Questions & Answers

Will the Advance Adapters 301506 fit a 1987 or newer Jeep?

No. It is not needed on 1987-and-newer Jeep vehicles. It is made for 1982–1986 Jeep CJ vehicles with an Atlas or Dana 300 transfer case, where it replaces the discontinued OEM holder S-2538608.

Is the speedometer drive gear included with the 301506?

No. The drive gear is sold separately as PN300620. The correct gear depends on speedometer calibration for your tire size and axle gear ratio, so choose it along with this holder.

What is the 301506 made from?

It is machined from billet aluminum to factory OEM specifications. Advance Adapters offers it as a replacement for the discontinued OEM holder, which was previously available only as a salvage or reconditioned part.

How do I tell if the speedometer drive gear is wrong?

Compare speedometer readings with GPS speed at a steady highway pace. A reading that runs consistently high or low suggests the gear does not match the tire size or axle ratio. Recheck the gear choice and have it changed if needed before relying on the speedometer.
