Overview
The Tuff Country 30925 is a front sway bar end link kit for Dodge Ram 2500 and 3500 trucks. It replaces part numbers 34003 and 36003 and includes hardware.
The kit uses heim joints to reduce suspension binding and improve articulation. Its threaded body fits stock height vehicles up to 3 inch of lift and works with Tuff Country lift kits from 2 inch to 6 inch.
Key features
- Heim joints to reduce suspension binding
- Threaded body for height adjustment
- Includes hardware
- Replacement for part numbers 34003 and 36003
- Front position
Heim joints and maintenance
Heim joints use a steel ball running in a race, which lets the link pivot in more than one direction. That movement cuts binding when the suspension cycles, but it also means dirt and water can reach the ball. Inspect the joint for play, rust on the ball and damaged seals, and clean away grit before it works into the bearing surface.
Because the threaded body sets the length, re-check the jam nut and the joint angle after any adjustment. Heavier trucks often carry more front axle load, so look at the mounting points and the bar bushings during the same job. Keep a record of the setting for your lift height so future adjustments start from a known point.
Specifications
| Brand | Tuff Country |
|---|---|
| Part number | 30925 |
| UPC | 698815309250 |
| Position | Front |
| Joint type | Heim joints |
| Lift range | Stock height up to 3 inch of lift |
| Lift kit compatibility | Tuff Country lift kits from 2 inch to 6 inch |
| Replaces | 34003 and 36003 |
| Hardware | Included |
Vehicle fitment
It fits the 2003–2010 Dodge Ram 2500 (Laramie, Power Wagon, SLT, ST, SXT, Sport, TRX and TRX4) and the 2003–2010 Dodge Ram 3500 (Laramie, SLT, ST, SXT, Sport and TRX4). It also fits the 2011–2013 Ram 2500 and the 2011–2012 Ram 3500 in several trims.
Confirm fit for your vehicle’s year, model and trim before buying, especially for Ram 1500 and 2013 Ram 3500 trucks.
Installation notes
The threaded body sets the length, so set it to suit your lift height. It fits stock height up to 3 inch of lift.
What’s included
The kit includes hardware. Check the package contents against your installation before starting.
