Overview
The SPOD 8 Circuit SE Add-On Touch Screen and Bluetooth, part number 8-700-TSB-C10, is a universal touchscreen controller for SPOD switch pod systems. The control module is a 3.5-inch LED-backlit TFT LCD screen in a billet aluminum case, with a universal articulating mount.
The touchscreen connects to SPOD’s SourceSE or Bantam power distribution module with a standard 10′ Ethernet cable. Short range Bluetooth LE is included and is used to customize the screen. It is universal fit and is not built for one specific vehicle.
Key features
- 3.5-inch LED-backlit TFT LCD screen
- 320 x 240 resolution with 16.7m colors
- 180-degree viewing angle
- Billet aluminum case
- Universal articulating mount
- Standard 10′ Ethernet cable connection to the power distribution module
- Short range Bluetooth LE for screen customization
Choosing a mounting spot
A touchscreen controller like this one is usually mounted where the driver can read it without looking away from the trail or road. The articulating mount lets you angle the screen, but the cable run should be planned first so the 10′ Ethernet lead does not pinch against pedals, the steering column or moving parts. Keep the screen clear of airbag zones and make sure the mount tightens fully so vibration does not drift the angle.
Before you buy, think about the power distribution module you already have or plan to add. A touchscreen only controls the circuits its module runs, so the screen and module need to belong to the same switch pod system. Re-check mount fasteners after the first few drives, since off-road vibration loosens hardware. Clean the screen with a soft cloth and avoid harsh solvents on the billet case finish.
- Route the Ethernet cable before drilling or mounting
- Check the screen angle from the driver seat
- Re-tighten the mount after the first few drives
Specifications
| Brand | SPOD |
|---|---|
| Part number | 8-700-TSB-C10 |
| UPC | 700008512331 |
| Circuits | 8 circuit |
| Display | 3.5-inch LED-backlit TFT LCD |
| Resolution | 320 x 240 |
| Colors | 16.7m |
| Viewing angle | 180 degrees |
| Case | Billet aluminum |
| Mount | Universal articulating mount |
| Connection | Standard 10′ Ethernet cable |
| Wireless | Short range Bluetooth LE |
Vehicle fitment
It is universal fit and is not built for a particular year, make, model or trim. It works with SPOD’s SourceSE or Bantam power distribution module.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Plan the route for the 10′ Ethernet cable between the touchscreen and the power distribution module before mounting the articulating mount. Disconnect power to the switch pod system before wiring any connection.
What’s included
The kit includes the touchscreen controller with its universal articulating mount. Check the package contents against your installation before starting.
Not included: the SourceSE or Bantam power distribution module, which the touchscreen connects to.
