Rubicon Express 3.5 Inch Progressive Coil Extreme Duty 4-Link Long Arm Lift Kit – JK4423P

Rubicon Express

Shop Rubicon Express Lift Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • 3.5-inch lift with a 4-link long arm system and progressive coil springs
  • Adjustable chromoly upper and lower control arms with Super-Flex spherical ball joints
  • PT-Meg Super-Ride bushings and a full-width transmission crossmember
  • No welding required for installation, per the manufacturer
  • Shocks not included; confirm fit by year, model and trim

Description

Overview

The Rubicon Express JK4423P is a 3.5-inch lift kit with a 4-link long arm suspension and progressive coil springs, offered in Rubicon Express’s JK suspension range. The kit is built around adjustable chromoly upper and lower control arms that carry Super-Flex spherical ball joints and PT-Meg Super-Ride bushings, and a full-width transmission crossmember adds frame stiffness where the drivetrain mounts.

The progressive coil springs are the main spring feature of this version. The kit does not include shock absorbers, so existing shocks can be reused or a separate set added. The system installs without welding and can be upgraded with an optional belly pan and a CNC-machined steering knuckle. Confirm fit for your vehicle’s year, model and trim before ordering.

Key features

  • 3.5-inch lift height, within the 3 to 4.99-inch range
  • 4-link long arm system with a progressive coil spring rear lift component
  • Adjustable chromoly upper and lower control arms
  • Super-Flex spherical ball joints
  • PT-Meg Super-Ride bushings
  • Full-width transmission crossmember
  • Installs without welding
  • Optional belly pan and CNC-machined steering knuckle

Choosing shocks for progressive springs

Progressive coil springs change their rate as they compress, so the ride is usually softer over small bumps and firmer when the suspension is loaded. That makes them a reasonable match for a vehicle driven on pavement and on trails. Because the springs are only part of the suspension, the shocks should be chosen with the springs in mind.

Existing shocks can often be reused if they are in good condition, but worn units tend to lose damping and can make a new spring feel loose. Look for leaks, cracked bushings and loose mounts before reinstalling. Replacing shocks at the same time as the springs is a common way to keep the ride balanced.

After installation, have the alignment and driveline angles checked and re-tighten fasteners after the first few drives.

Specifications

Brand Rubicon Express
Part number JK4423P
UPC 700008140161
System type Extreme-duty 4-link long arm with progressive coils
Lift height 3.5 inches (manufacturer range 3 to 4.99 inches)
Spring type Progressive coil
Control arms Chromoly upper and lower, adjustable
Joints Super-Flex spherical ball joints
Bushings PT-Meg Super-Ride
Transmission crossmember Full width
Shocks Not included

Vehicle fitment

It belongs to the JK suspension range. Confirm fit for your vehicle’s year, model and trim before ordering.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Replacing the factory suspension with a 4-link long arm layout changes control arm angles and pinion geometry. Have the alignment and driveline angles checked after the kit is installed, since the arm geometry is different from the factory setup.

What’s included

The named parts are the adjustable upper and lower control arms, the progressive coil springs, the Super-Flex spherical ball joints, the PT-Meg Super-Ride bushings and the full-width transmission crossmember.

Not included: shock absorbers. The belly pan and steering knuckle are optional upgrades rather than part of this kit.

SKU: R/EJK4423P Category:

Specification

Shipping weight 246.15 lbs
Package dimensions 0.00 × 0.00 × 0.00 in
brands

Questions & Answers

Are shocks included with the JK4423P?

No. The fitment details for this kit list shocks as not included, so existing shocks can be reused or a separate set bought for the 3.5-inch height. The kit's progressive coil springs and control arms do not come with shock absorbers.

What spring type does this kit use?

It uses progressive coil springs as its rear lift component. The kit raises the vehicle 3.5 inches, within the 3 to 4.99-inch range for this system.

Does the kit need any welding during installation?

No welding is required for the install. The full-width transmission crossmember is designed to simplify the job, and the adjustable control arms are set during installation. Have the alignment and driveline angles checked once the kit is in place.

Which vehicles does the JK4423P fit?

The JK4423P belongs to Rubicon Express's JK suspension range. Confirm your vehicle's year, model and trim before ordering the parts, and check the package contents against your installation.

How do progressive coil springs affect the ride?

Progressive springs stiffen as they compress, so small bumps feel softer while larger loads are controlled. Shock selection still matters, since the springs and shocks work together. Check shocks for leaks and worn bushings during installation.
