Overview
The Rough Country 4-to-5-inch Toyota suspension lift kit, part number R/C734.20, fits the 1989–1995 Toyota Pickup in DLX and SR5 versions. It raises the front independent front suspension (IFS) by lowering the lower control arms with front and rear crossmember drop brackets.
The upper control arms stay in their factory location, and lifted cast knuckles connect the upper and lower control arms. The front differential is lowered to maintain proper CV angles.
The recommended tire size is 33×12.50, with a recommended wheel backspacing of 3.75 inches.
Key features
- Lowered lower control arms through IFS drop brackets
- Lifted cast knuckles
- Front and rear crossmember drop brackets
- Front differential lowered to maintain CV angles
- Recommended tire size 33×12.50
- Recommended wheel backspacing of 3.75 inches
Before you install
A lift on an independent front suspension changes several parts at once, so the work is worth planning. Lowering the lower control arms shifts the steering and driveline geometry, which is why the front alignment and CV angles need attention after the install. The new position can also change how brake lines, sway bar links and shock mounts sit, so check them for stretch or contact before the first drive.
Wear items are often replaced at the same time. Ball joints, tie rod ends and CV boots are worth inspecting before the kit goes on, since altered angles put extra load on aging joints. Re-torque all fasteners after the first few drives and listen for new noise in the front end.
- Inspect ball joints and tie rod ends before installation
- Recheck brake line and sway bar link clearance after the first drive
- Look at CV boots for cracks once the angles are set
Specifications
| Brand | Rough Country |
|---|---|
| Part number | R/C734.20 |
| Lift size | 4 to 5 inches |
| Front suspension | IFS with lowered lower control arms |
| Knuckles | Lifted cast |
| Recommended tire size | 33×12.50 |
| Recommended wheel backspacing | 3.75 inches |
| Fitment type | Direct fit |
Vehicle fitment
It fits the 1989–1995 Toyota Pickup in DLX and SR5 versions.
It does not fit 1996 Tacoma or extended cab models. Other Toyota models fall outside this kit’s fit.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Lowering the lower control arms and the front differential changes the driveline and the alignment, so check the CV angles and have the front alignment set after installation.
What’s included
Lifted cast knuckles, front and rear crossmember drop brackets, and the lower control arm and differential drop components.
