Overview
The R-Series 46 Marine LED Light, part number 83421, is a circular marine light with a curved lens and housing. It is the brand’s first circular light and is universal fit, so it is not built for a particular vehicle.
The light works as a spotlight, in a fog light position, or wherever strong light output is needed. It comes in several beam patterns, so confirm the beam pattern of this part number before choosing it.
Key features
- Circular form with a curved lens and curved housing
- Compact design with optics and an advanced heat sink
- Spot, Hyperspot, Flood, Combo, Driving and Wide beam patterns
- LED light for spotlight or fog light positions
Wiring and mounting planning
A high-output LED light draws enough current that the wiring and switch need to be sized for it. Running the light through a fuse close to the battery and switching it with a relay keeps the load off the dash switch. Plan the mounting location so the light is protected from direct spray and from contact with the boat’s gear.
Marine installs take a beating from vibration and water, so connectors should be sealed and cable runs secured clear of moving parts. Check the mounting hardware after the first few outings, because vibration can loosen fasteners that were tight at install. Keep the lens and heat sink clean so the light can shed heat as designed.
- Fuse the circuit close to the power source
- Use a relay for the high-output load
- Seal and secure every connection
- Re-check fasteners after the first outings
Specifications
| Brand | Rigid Industries |
|---|---|
| Part number | 83421 |
| UPC | 849774011078 |
| Series | R-Series 46 |
| Type | Marine LED light |
| Beam patterns offered | Spot, Hyperspot, Flood, Combo, Driving, Wide |
| Fitment | Universal Fit |
Vehicle fitment
Fitment is universal, so the R-Series 46 is not tied to a particular year, make or model. Its use depends on the mounting and setup you choose.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
High-output LED lights are typically wired through a fuse and relay, so plan the circuit that way. Check local rules for marine lighting before installing.
What’s included
The package contains the light only. Check the contents against your installation before starting.
