Overview
The ReadyLift 26-1920 is a 2-inch rear spacer kit for the 2014–2021 Ram 2500 4WD. It raises the rear of the truck, which ReadyLift says helps with heavy towing or hauling and also gives owners a more raked stance if they want one.
The rear block and spacer kits are engineered to set the correct pinion angle, the factory bump stop distance and the right locator pin position for easy installation. Rear lift in this range runs from 1 inch to 6 inch depending on the vehicle, and this 2-inch kit is one option within it. Rear block and spacer kits from the SST lift line are sold individually. Owners who want a raked stance rather than extra tow height can use the rear kits for either need, and the 2-inch option can be compared with the other rear heights.
Key features
- 2 inch rear lift
- Rear spacer kit for 4WD models
- Designed for the 2014 and later Ram 2500
- Engineered for correct pinion angle and bump stop distance
- Locator pin position set for installation
Rear lift and driveline angles
Raising the rear changes the angle of the driveshaft joints and the pinion relative to the transmission. Small changes are normal, but larger angles can cause vibration at highway speeds if the driveline is worn. Matching the pinion angle and locator pin position helps keep the axle in the correct place under load, which matters for towing and hauling.
A rear lift also affects the rear shocks, brake lines and the track bar geometry. Longer shocks or relocated brackets may be needed for some setups, so measure the rear clearance and check the brake hose length before driving. Owners who tow often may want to check the rear bump stops periodically, since the load works them harder.
- Measure driveshaft angles after installation
- Inspect the U-bolts and locator pins for movement
- Check brake hose length and routing
- Recheck the rear height after the first loaded trip
Specifications
| Brand | ReadyLift |
|---|---|
| Part number | RDY26-1920 |
| Rear lift height | 2 inch |
| Type | Rear |
| Drivetrain | 4WD models |
| Fitment | Direct fit |
Vehicle fitment
It fits the 2014–2021 Ram 2500 in the Big Horn, Laramie, Laramie Limited, Laramie Longhorn, Limited, Limited Longhorn, Lone Star, Outdoorsman, Power Wagon, SLT and Tradesman trims.
The kit is for 4WD models only. Confirm the year, model, trim and drivetrain match your truck before ordering, including whether it is a 2500 4WD.
Installation notes
The rear block kits include longer U-bolts designed for the vehicle and the amount of lift. The rear is set to the correct pinion angle, and the kit uses the factory bump stop distance and the correct locator pin for easy installation. A rear lift changes driveline angles, so check the driveshaft angles after the install.
