Overview
The ReadyLift 69-2511TP is a 2.5-inch front and 2.0-inch rear SST lift kit for 2011 to 2016 Ford F-250 and F-350 Super Duty 4WD trucks. It is the tow package version, designed to give a slight rake for towing or hauling and to fit tires up to 35 inches while keeping the factory ride. Fitment covers King Ranch, Lariat, Platinum, XL and XLT versions of both trucks.
The kit includes a 5.0-inch OEM-style cast iron rear block that replaces the factory block, giving near-factory rake with the lifted stance. Its parts are 2.5-inch powder coated steel coil spring spacers, sound isolators, shock extensions, sway bar frame mount spacers, bump stop extensions, a carrier bearing spacer and a track bar relocation bracket. Ford changed the front suspension on the 2011 to 2016 trucks, so the sway bar frame mounts are spaced down.
Key features
- 2.5 inches of front lift and 2.0 inches of rear lift
- 5.0-inch OEM-style cast iron rear lift blocks replacing the factory block
- 2.5-inch powder coated steel coil spring spacers with sound isolators
- Shock extensions that keep the factory front shocks in use
- Sway bar frame mount spacers for the 2011 to 2016 front suspension
- Carrier bearing spacer for driveshaft angle adjustment
- Track bar relocation bracket
Choosing a tow package setup
A tow package lift suits owners who haul or tow regularly. The goal is a level or slightly raked stance so the rear sits well under load, and the rear block choice affects how close the truck gets to factory height. Consider typical loads, the trailer hitch and the tires you plan to run before deciding how much rake you want.
Air bags and load leveling accessories interact with lift blocks, so confirm any add-on fits the setup before purchase. Carrier bearing supports and driveshaft angles should be checked after installation, and a loaded trip is a good way to listen for driveline vibration. Keep the bump stop extensions and shock extensions free of damage, since they work every time the suspension travels.
Specifications
| Brand | ReadyLift |
|---|---|
| Part number | RDY69-2511TP |
| Front lift | 2.5 inches |
| Rear lift | 2.0 inches |
| Rear block | 5.0-inch cast iron, OEM style, replaces factory block |
| Tire clearance | Up to 35 inches |
| Driveshaft | One-piece driveshaft trucks only |
| Shock extensions | Included; front shocks retained |
| Warranty | Lifetime against manufacturing defects |
| Fitment type | Direct fit |
Vehicle fitment
The kit fits trucks with a one-piece driveshaft only. Trucks outside 2011 to 2016 are not covered, so check year, model and trim before ordering.
It is not designed to work with aftermarket or factory air spring or load leveling kits that attach to the bump stop tangs.
Installation notes
No cutting or drilling is needed. The carrier bearing spacer lets the installer adjust driveshaft angle as needed, and the track bar relocation bracket is fitted as part of the front setup. Set an alignment after installation and check the driveline angles.
What’s included
The kit includes the 5.0-inch rear blocks, 2.5-inch coil spring spacers, sound isolators, shock extensions, sway bar frame mount spacers, bump stop extensions, the carrier bearing spacer and the track bar relocation bracket.
