Overview
The Pro Comp 252-5883F is a Series 252 Street Lock 15×8 steel wheel in Flat Black with a 6 on 5.5 bolt pattern. It has an offset of -19, a backspacing of 3.75 and a center bore of 108, with a windowed style.
Rock Crawler Xtreme Series 252 steel wheels come in a range of sizes and backspacings, with a durable gloss or flat black powder coating. This wheel measures 15 inches across and 8 inches wide, and the center cap and lug nuts are separate items.
Key features
- 15 inch diameter, 8 inch width
- 6 on 5.5 bolt pattern
- Offset -19 and backspacing 3.75
- Center bore 108
- Steel construction
- Windowed style
- Flat Black finish
- Part of the Rock Crawler Xtreme Series 252
Offset and backspacing explained
Offset is the distance from the wheel’s mounting face to its centerline, and backspacing is the distance from the mounting face to the inner lip. Together they decide where the wheel sits relative to the hub, the brake caliper and the fender. A wheel with a different offset or backspacing can rub or stand too far out even when the bolt pattern matches, so compare these figures with your vehicle before mounting.
Steel wheels are heavier than aluminum wheels of the same size, and their windowed design can trap mud on the trail. Rinse the wheel after off-road use and inspect the powder coating for chips, since bare steel can start to rust. Tire choice matters as well, because tire width and sidewall height change overall diameter and clearance.
- Check clearance at the brake caliper and fender
- Inspect powder coat for chips after trail use
- Match tire width and diameter to available clearance
Specifications
| Brand | Pro Comp Steel Wheels |
|---|---|
| Part number | 252-5883F (also written PCW252-5883F) |
| Product type | Wheel |
| Series | 252 Series (Rock Crawler Xtreme) |
| Style | Windowed |
| Wheel diameter | 15 inches |
| Wheel width | 8 inches |
| Bolt pattern | 6 on 5.5 |
| Offset | -19 |
| Backspacing | 3.75 |
| Center bore | 108 |
| Construction | Steel |
| Finish | Flat Black |
| Fit type | Universal |
Vehicle fitment
The wheel is universal fit, which refers to the wheel itself rather than a particular vehicle. It has a 6 on 5.5 bolt pattern.
Wheel fitment depends on bolt pattern, center bore, offset, backspacing, brake clearance and tire size. Check that the 6 on 5.5 bolt pattern and the 108 center bore suit your vehicle. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Wheels and tires are safety-critical, so professional mounting and balancing are a sound choice. Confirm the bolt pattern, offset and clearance for your vehicle before installation, and tighten lug nuts in a star pattern to the torque value for your vehicle.
Re-check lug nut torque after the first miles of driving, and check clearance to the brakes, suspension and body through full steering and suspension travel.
What’s included
- Series 252 steel wheel, 15×8, Flat Black
Not included: the center cap and lug nuts, which are separate items, or tires.
