Pro Comp 252 Series Street Lock, 15x10 Wheel with 5 on 4.5 Bolt Pattern – Gloss Black – 252-5165

Pro Comp Steel Wheels

Shop Pro Comp Steel Wheels 15x10 5x4.5 on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Steel windowed wheel, 15×10, gloss black
  • Part number PCW252-5165; 5 on 4.5 bolt pattern
  • Center bore 83; offset -44; backspacing 3.75
  • Center cap and lug nuts sold separately

Description

Overview

The Pro Comp PCW252-5165 is a 15×10 steel wheel from the 252 Series Street Lock line, with a windowed face and a gloss black powder coat. It has a 5 on 4.5 bolt pattern, a center bore of 83, an offset of -44 and a backspacing of 3.75.

The 252 Series belongs to Pro Comp’s Rock Crawler Xtreme wheels, built with a durable gloss or flat black powder coat. The center cap and lug nuts are sold separately.

The 5 on 4.5 pattern and 83 center bore need to match the hub, and the -44 offset sets the wheel’s mounting face well inboard of a standard wheel of the same width. Check the inner clearance to the suspension and the brake assembly before mounting.

The 15-inch diameter and 10-inch width need a tire sized for that rim. This windowed steel wheel is the style used in the 252 Series.

Key features

  • Steel construction with gloss black powder coat
  • Windowed wheel design
  • 5 on 4.5 bolt pattern
  • Offset -44 and backspacing 3.75
  • Center cap and lug nuts sold separately

Offset, clearance and tire fit

Offset decides where the wheel sits in the wheel well, and a -44 offset pushes the mounting face inboard. That moves the tire inward, which can change clearance at the control arms, springs, brake hardware and the inner fender. Before mounting, check the inner clearance with the tire fitted, and turn the steering both ways to look for rubbing.

Wheel width and diameter also affect tire choice. A 15-inch rim takes a narrower range of tire sizes than a larger rim, and load rating matters for trail loads. Use a wheel spacer only after confirming the hub and clearance, and check that the lug nut seats match the wheel. Inspect the wheel after hard impacts for cracks around the windows.

Specifications

Brand Pro Comp Steel Wheels
Part number PCW252-5165
Diameter 15 inches
Width 10 inches
Bolt pattern 5 on 4.5
Center bore 83
Offset -44
Backspacing 3.75
Style Windowed
Finish Gloss black
Construction Steel
Series 252 Series Street Lock

Vehicle fitment

It is a universal fit, so confirm the 5 on 4.5 pattern, 83 center bore and -44 offset match your truck, and check that the wheel clears the suspension and brakes.

Tire size and load rating must suit a 15×10 wheel. Confirm your vehicle’s year, model and trim before ordering.

What’s included

One steel wheel. The center cap and lug nuts are sold separately.

SKU: PCW252-5165 Categories: ,

Questions & Answers

Does this steel wheel come with a center cap?

No. The center cap and lug nuts are sold separately, so they need to be bought as extras. Check the fit of the caps and nuts against your hub before ordering, since the wheel ships without them.

What bolt pattern and offset does the 252 Series wheel use?

It has a 5 on 4.5 bolt pattern, a center bore of 83, an offset of -44 and a backspacing of 3.75.

Is this wheel vehicle-specific?

No. It is a universal fit rather than built for one vehicle. Check the 5 on 4.5 bolt pattern, 83 center bore and -44 offset against your truck before buying.

Can the windowed design be cleaned without damage?

Yes. Rinse the wheel and use a mild soap and a soft brush, avoiding harsh solvents on the gloss black finish. Dry it fully so road grime does not settle into the window edges.

Should lug nuts be checked after mounting?

Yes. Check the lug nuts after the first few drives, because new wheels can settle slightly against the hub. Retighten them to the vehicle's specification and recheck after the next few trips.
